Intel Desktop Board DZ77SL-50K Technical Product Specification
24
1.5.3 USB
The PCH contains up to two Enhanced Host Controller Interface (EHCI) host controllers
that support USB high-speed signaling. High-speed USB 2.0 allows data transfers up to
480 Mb/s. All ports are high-speed, full-speed, and low-speed capable.
The PCH also contains an integrated eXtensible Host Controller Interface (xHCI) host
controller which supports USB 3.0 ports. This controller allows data transfers up to
5 Gb/s. The controller supports SuperSpeed (SS), high-speed (HS), full-speed (FS),
and low-speed (LS) traffic on the bus.
The board supports up to eight USB 2.0 ports and four USB 3.0 ports.
The Intel Z77 Express Chipset provides the USB controller for the 2.0/3.0 ports. The
port arrangement is as follows:
• Two USB 3.0 ports are implemented with stacked back panel connectors (blue)
• Two front panel USB 3.0 ports are implemented through one internal connector
(blue)
• Four USB 2.0 ports are implemented with stacked back panel connectors (black)
• Four USB 2.0 front panel ports are implemented through two internal headers
NOTE
Computer systems that have an unshielded cable attached to a USB port may not
meet FCC Class B requirements, even if no device is attached to the cable. Use a
shielded cable that meets the requirements for full-speed devices.
For information about Refer to
The location of the USB connectors on the back panel Figure 9, page 44
The location of the front panel USB headers Figure 10, page 45
1.5.4 SATA Interfaces
The board provides six SATA connectors, through the PCH, which support one device
each:
• Two SATA 6.0 Gb/s interfaces through the Intel Z77 Express Chipset with Intel
®
Rapid Storage Technology RAID support (blue)
• Three internal Serial ATA (SATA) 3.0 Gb/s interfaces through the Intel Z77 Express
Chipset with Intel Rapid Storage Technology RAID support (black)
• One back panel eSATA port (red)
The PCH provides independent SATA ports with a theoretical maximum transfer rate of
6.0 Gb/s for two ports and 3.0 Gb/s for four ports. A point-to-point interface is used
for host to device connections.
The PCH supports the Serial ATA Specification, Revision 3.0. The PCH also supports
several optional sections of the Serial ATA II: Extensions to Serial ATA 1.0
Specification, Revision 1.0 (AHCI support is required for some elements).
The underlying SATA functionality is transparent to the operating system. The SATA
controller can operate in both legacy and native modes. In legacy mode, standard IDE
