Intel Desktop Board DZ77SL-50K Technical Product Specification
56
Table 30. BIOS Setup Configuration Jumper Settings
Function/Mode Jumper Setting Configuration
Normal
1-2
The BIOS uses current configuration information and passwords
for booting.
Configure
2-3
After the POST runs, Setup runs automatically. The
maintenance menu is displayed.
Note that this Configure mode is the only way to clear the
BIOS/CMOS settings. Press F9 (restore defaults) while in
Configure mode to restore the BIOS/CMOS settings to their
default values.
Recovery
None
The BIOS attempts to recover the BIOS configuration. A
recovery CD or flash drive is required.
