Intel Desktop Board DZ77SL-50K Technical Product Specification
62
2.7 Reliability
The Mean Time Between Failures (MTBF) prediction is calculated using component and
subassembly random failure rates. The calculation is based on the Telcordia SR-332,
Issue 2; Method I Case 3 50% electrical stress, 55 ºC ambient. The MTBF prediction is
used to estimate repair rates and spare parts requirements. The MTBF data is
calculated from predicted data at 55 ºC. The MTBF for the Intel Desktop Board
DZ77SL-50K is 255,651 hours.
2.8 Environmental
Table 36 lists the environmental specifications for the board.
Table 36. Environmental Specifications
Parameter Specification
Temperature
Non-Operating
-20 °C to +70 °C
Operating
0 °C to +55 °C
Shock
Unpackaged 50 g trapezoidal waveform
Velocity change of 170 inches/s²
Packaged Half sine 2 millisecond
Product Weight (pounds) Free Fall (inches) Velocity Change (inches/s²)
<20 36 167
21-40 30 152
41-80 24 136
81-100 18 118
Vibration
Unpackaged 5 Hz to 20 Hz: 0.01 g² Hz sloping up to 0.02 g² Hz
20 Hz to 500 Hz: 0.02 g² Hz (flat)
Packaged 5 Hz to 40 Hz: 0.015 g² Hz (flat)
40 Hz to 500 Hz: 0.015 g² Hz sloping down to 0.00015 g² Hz
