16
Planning Installation
Description Q'ty Size Remarks
Antenna Control Unit (ACU) 1 431x350x44.3 mm Antenna Control Unit (ACU)
Quick Installation Guide (QIG) 1
RF Hazard Sticker 1 Radiation Safety Distance (15m) Label
Mounting Template 1
ACU Rack Mount Bracket 2 To x ACU to 19inch Rack Frame
Flat Head Screw 10 M4x12L Bolt Kit for Rack Type Mount Bracket
USB Cable (A-A) 1 1.8m ACU (Front Panel) to PC
AC Power Cord (CEEE7/7) 1 1.5m ACU Power (220V)
RG-6 RF Cable 2 1m ACU to Modem
Modem Interface Cable
(For iDirect Modem)
1 1.5m ACU to Modem (iDirect Modem)
Ethernet Cable (RJ45/LAN) 2 1m ACU to PC/Intellian M&C
Wi-Fi Dongle 1
Hex Bolt 5 M12x80L
Bolt Kit to Install Antenna to Antenna
Mast (1 Spare Set Included)
Flat Washer 5 M12
Spring Washer 5 M12
Hex Head Wrench Bolt 5 M6x40L
Spare Bolt Kit for Radome AssemblySpring Washer and Flat Washer 5 M6
Sems Bolt 2 M4x8L
Radome Door Key 2 Two Door Keys
Waterproof Foam 1 X-shape Cable Hole Type
ACU Components Box (Optional: for Dual Antenna System)
To Next Page
