ADDRESSING
Once the reader is wired into the system, the module needs to be addressed. Unlike most
NetworX expanders, the address of any particular reader is determined by itself after installation
is complete. Follow the procedures outlined under the section “PROGRAMMING”. When prompted
to enter the module device number, a card must be scanned at the reader to initiate addressing
(one short beep). When completed (1-2 seconds), the reader will beep back its address (long
beeps). Refer to Table 0-1 that follows for possible addresses.
Scan: To
“present” or
pass a card or
FOB within
sensing range of
the card reader
module.
Table 0-1
Beeps Address Beeps Address
1 113 9 121
2 114 10 122
3 115 11 123
4 116 12 124
5 117 13 125
6 118 14 126
7 119 15 127
8 120
PROGRAMMING
USING THE LED KEYPAD
Only NX-13xx keypad series allow to program user cards.
ACTION RESULT
Entering the Program Mode
& Á _
x x x x x x x x
Enters the Program Mode.
Stay, Chime, Exit, Bypass & Cancel LEDS will flash.
& [Go To Program Code]
Factory Default is `^XZ
x x x x x x x x
If the "Go To Program Code" is valid, the "Service"
LED will flash and the 5 function LEDs will illuminate
steady. You are now in the Program Mode and
ready to select the module address.
Entering the Module Address
Scan a card.
x x x x x x x x
The card reader will address itself.
& XYW #
(example only)
x x x x x x x x
Enters the module address. Refer to Table 0-1 on
page 5 for the address assigned by the card reader
module itself.
The Armed LED will illuminate while it is waiting for a
programming location to be entered.
NX-1701E Installation manual Page 5 31/01/05
