Programming a Location
 If an attempt is made to program an invalid entry for a particular segment, the keypad
sounder will emit a triple error beep (beep, beep, beep), and remain in that segment
awaiting a valid entry.
To Enter a Location:
& [location] #
x x x x x x x x
The Armed LED will flash. If the location is valid, the
"Armed" LED will extinguish, the "Ready" LED will
illuminate, and the zone LED’s will show the data for
the first segment of this location.
To Change Location Data:
& [changed data]
x x x x x x x x
The "Ready" LED will flash to indicate a data change
in process and will continue until the data is saved.
& À
x x x x x x x x
The new data is saved.
The keypad will increment and display the next
segment’s data.
NOTE: Repeat these steps until the last
segment is reached.
To Exit a Location:
& #
x x x x x x x x
Exits from this location. The “Ready” LED will
extinguish. The "Armed" LED will illuminate waiting
for a new programming location to be entered.
To Review The Data:
& [location] #
x x x x x x x x
The Armed LED will flash. If the location is valid, the
"Armed" LED will extinguish, the "Ready" LED will
illuminate, and the zone LED’s will show the data for
the first segment of this location.
& À
x x x x x x x x
(Do not enter data.)
The next segment is displayed. Each time
 is
pressed, the data of the next segment will be
displayed for review.
Shortcuts:
&
Previous location.
&
Same location.
&
Next sequential location.
Exiting the Program Mode:
& EXIT EXIT
x x x x x x x x
Exits this programming level.
NX-1701E Installation manual Page 6 31/01/05
