INVT Goodrive100-PV Series User Manual

Goodrive100-PV Series Solar Pumping VFD Function parameters
57
Function
code
Name
Detailed illustration of parameters
Default
Modify
P18.15
Total pump flow
resetting
Setting this value to 1 can reset the total
pump flow. P18.13 and P18.14 will
accumulate the flow after resetting.
After the resetting succeeds, P18.15 is
automatically set to 0.
0
◎
P19 Group Voltage boost (inverter module communicates with boost module
through 485)
P19.00
Boost voltage loop
KP
0.000–65.535
0.500
○
P19.01
Boost voltage loop
KI
0.000–65.535
0.080
○
P19.02
Boost current loop
KP
0.000–65.535
0.010
○
P19.03
Boost current loop
KI
0.000–65.535
0.010
○
P19.04
Upper limit of the
output current of
boost voltage loop
PI
Upper limit output of mppt voltage loop
PI, upper limit of the boost current loop
reference current
P19.05–15.0A
12.0A
○
P19.06
Bus reference
voltage
This function code is set to the bus
reference voltage at PV input when the
system contains the boost module. By
default, this function code is set to 350V
for models of 220V and 570V for models
of 380V.
Setting range: 300.0V–600.0V
350.0V
◎
P19.07
Boost voltage loop
KP1
If the difference between the bus
reference voltage and actual bus
voltage is greater than 20V, the boost
0.500
○
