Power Supply Function

11. Based on the selected trigger method, perform the trigger operation.

• Programming via SCPI instructions

For detailed instructions and parameter introduction, please refer to the in-

structions of "ARB Subsystem" in the Programming Guide.

• Realized by the software IT9000 on PC

For detailed function usage, please refer to IT9000–PV6000 User Manual.

4.6.2 Battery Charging/Discharging Test Function

The IT6000C series power supply provides the battery charging/discharging test

function based on its unique bidirectional power supply properties. Suitable for

charging/discharging tests on all types of portable batteries.

• When connecting the DUT (battery/capacitor), do not short-circuit

the battery/capacitor.

• It is recommended that for battery testing, a fuse must be con-

nected in series between the power supply and the battery to pre-

vent short circuits caused by any problems.

• When connecting the DUT (including but not limited to battery/ca-

pacitor), it is recommended that you purchase the IT-E165A anti-re-

verse connection and anti-spark module to prevent the battery/

capacitor reverse connection that may cause damage to the instru-

ment and spark during the battery/capacitor wiring; When there is

no external auxiliary equipment connected to prevent reverse con-

nection and anti-spark function, please pay attention to the safety

of the wiring, and be careful not to reverse the battery/capacitor

connection, reverse connection will cause damage to the instru-

ment, even if it is not powered on.

• Before performing the battery test, you need to connect the Sense

cables to both ends of the battery. If the Sense cables are not con-

nected, the instrument cannot detect the Sense voltage and prompt

“Wait Power Link”, which will prevent the battery test from

continuing.
