TECHNICAL INFORMATION
Technical information
Technical information 3-phase models
Model Greenline HT Plus C/E 6 C/E 7 C/E 9 C/E 11 E 14 E 17
Emitted /Supplied output at 0/35°C
1
kW 5,9/1,3 7,3/1,6 9,1/2 10,9/2,17 14,4/3,1 16,7/3,7
Emitted /Supplied output at 0/50°C
1
kW 5,4/1,7 6,9/2,1 8,4/2,6 10,1/2,9 13,9/4,2 16,2/4,9
Minimum fl ow heating medium l/s 0,14 0,18 0,22 0,26 0,35 0,40
Nominal fl ow heating medium l/s 0,20 0,25 0,31 0,38 0,50 0,57
Permitted ext. pressure drop heating
medium nominal fl ow
kPa 36 36 34 32 54 51
Nominal fl ow heat transfer fl uid medium l/s 0,30 0,38 0,46 0,57 0,78 0,90
Permitted ext. pressure drop heat transfer
fl uid medium nominal fl ow
kPa 49 45 44 80 74 71
Heat transfer fl uid Bio-ethanol/water or Propylene glycol/water
Max pressure radiator system bar 1,5
Max pressure heat transfer fl uid medium bar 4
Highest outgoing heating medium
temperature
°C 65
Operating temperature heat transfer system °C -10 to +20
Integrated heat/HTF pump Yes
Electrical supply 400V 3N~ 50Hz
Add. heat reconnectable kW 3,0 / 6,0 / 9,0
Recommended fuse size depends on
electrical additional heat
2
Electric cassette 6 kW
Electric cassette 9 kW
A161620202025
A202025252532
Compressor Scroll
Refrigerant R-407C kg 1,35 1,4 1,5 2,2 2,2 2,3
Connection, heat transfer fl uid mm Cu 22 Cu 22 Cu 22 Cu 22 Cu 28 Cu 28
Connection, heat transfer fl uid (coll) mm Cu 28 Cu 28 Cu 28 Cu 28 Cu 35 Cu 35
Dimensions E-model (WxDxH) mm 600x600x1520
Weight E-model kg 146 152 155 175 190 195
Dimensions C-model (WxDXH) mm 600x600x1800 - -
Weight C-model
Copper/Stainless steel hot water-cylinder kg 230/200 231/201 240/210 223 -
-
Integrated double-shelled hot water-cylinder
on the C-model. Copper or stainless
3
Copper /
stainless
Copper /
stainless
Copper /
stainless
Stainless - -
Hot water cylinder C-model litres 185 185 185 185 - -
Control unit Rego 637
1
Output data at 0/35°C and 0/50°C and min heating medium fl ow are stated according to the European standard EN 255.
Additional heat not included.
2
Melt fuse breaker type gL-gG or miniature circuit breaker with characteristic C.
3
Anode included with C-models with stainless hot water cylinder.
