TECHNICAL INFORMATION
Technical information 1-phase models
Model Greenline HT Plus C/E 6 C/E 7 C/E 9 C/E 11
Emitted /Supplied output at 0/35°C
1
kW 5.7/1.4 7.2/1.7 9.1/2.1 10.6/2.4
Emitted /Supplied output at 0/50°C
1
kW 5.4/1.7 6.8/2.2 8.5/2.7 10.0/3.2
Minimum fl ow heating medium l/s 0.14 0.18 0.22 0.26
Nominal fl ow heating medium l/s 0.20 0.25 0.31 0.38
Permitted ext. pressure drop heat carrier
medium nominal fl ow
kPa 36 36 34 33
Nominal fl ow heat transfer fl uid medium l/s 0.30 0.38 0.46 0.57
Permitted ext. pressure drop heating
medium nominal fl ow
kPa 49 45 44 80
Heat transfer fl uid Bioethanol/water or Propylene glycol/water
Max pressure radiator system bar 1.5
Max pressure heat transfer fl uid medium bar 4
Highest outgoing heating medium
temperature
°C 65
Operating temperature heat transfer system °C -5 to +20
Integrated heat/HTF pump Yes
Electrical supply 230V 1N~ 50Hz
Add. heat reconnectable kW 3.0 / 6.0 / 9.0
Recommended fuse size depends on electric
additional heat
2
Electric cassette 6 kW
Electric cassette 9 kW
A40405050
A50636363
Compressor Scroll
Refrigerant R-407C kg 1.35 1.4 1.5 1.9
Connection, heat transfer fl uid mm Cu 22 Cu 22 Cu 22 Cu 22
Connection, heat transfer fl uid (coll) mm Cu 28 Cu 28 Cu 28 Cu 28
Dimensions E-model (WxDxH) mm 600x600x1520
Weight E-model kg 146 152 155 170
Dimensions C-model (WxDxH) mm 600x600x1800
Weight C-model
Copper/Stainless hot water cylinder kg 230/200 231/201 240/210 218
Integrated double-shelled hot water cylinder
on the C-model. Copper or stainless
3
Copper /
Stainless
Copper /
Stainless
Copper /
Stainless
Stainless
Hot water cylinder C-model litres 185 185 185 185
Control unit Rego 637
Technical information
1
Output data at 0/35°C and 0/50°C and min heating medium fl ow are stated according to the
European standard EN 255.
Additional heat not included.
2
Melt fuse breaker type gL-gG or miniature circuit breaker with characteristic C.
3
Anode included with C-models with stainless hot water cylinder.
