113
> Change from previous revision
1
2
3
4
4
5
6
7
8
9
9
10
TURFCAT T628D
Item Part No. Qty. Description Serial Numbers/Notes
1
2721416-01 1 Wheel Motor, Left Rear
64162-08 1 • Key, 5/16 x 1” Woodruff
148138 1 • Seal Kit
2 2721430 1 • Cartridge
3 2721430-01 1 • • Check Valve
2721430-02 1 • • • Seal Kit
4 2721430-03 4 • • Bolt
5 2721430-04 1 • • Plug
6 4114190-01 Wheel Motor, Right Rear
64162-08 1 • Key, 5/16 x 1” Woodruff
148138 1 • Seal Kit
7 4114189 1 • Cartridge
8 2721430-01 1 • • Check Valve
2721430-02 1 • • • Seal Kit
9 2721430-03 4 • • Bolt
10 2721430-04 1 • • Plug
46.1 Rear Wheel Motors
Part Numbers 2721416-01 and 4114190-01
Serial No. All
To Next Page
