105
J-460/465/470/480
Druckwächter
Begrenzungsfühler/Frostfühler
Temperaturfühler
Heizgerät
2,7 kW - 220/240V
1~ 50 Hz
Versorgung
(zusätzlich)
Umwälz-
pumpe
Pumpe 2
Pumpe 1
N
L
Haupt-
bedien-
feld
Transformator
Lichtsteuerung LED
Ozonerzeuger
(Option)
220/240V 1~ 50 Hz
Sinto CD-
Player (Option)
zu den Relais des Heizgerätes
12 VCA Lichtaustritt Wasserfall
Lichtsteuerung Schacht
N
L
