2.3.1 Additional materials
The following are required for the installation of the
controller and must be supplied by the installer:
1. A minimum of two (2) fasteners to mount the controller
back plate to a wall or electrical box. The fasteners
should be suitable for the surface where the controller is
to be remotely mounted.
2. A high-voltage disconnect switch, as required by the
National Electrical Code
®
(NEC
®
), within line of sight of
the pump.
2.4 Installation of the Backplate onto an
Electrical Box
CAUTION
Do not expose the user interface to direct
sunlight. Too much direct sunlight will darken
the LCD screen, and it will no longer be
readable.
1. Turn off the pump at the control panel.
2. Turn off all electrical power to the pump at the main
junction box or at the circuit breaker providing electrical
power to the pump.
WARNING
ELECTRICAL SHOCK HAZARD
Turn off all switches and the main breaker in
the ePump electrical circuit before starting the
procedure. Failure to comply may cause a shock
hazard resulting in severe personal injury or death.
3. Carefully detach the backplate from the controller
by removing the six (6) screws from the front of the
controller. Do not tug on the cable that is attached to the
backplate in order to avoid damge to the cable or terminal
block.
4. The backplate has nine (9) mounting holes to choose
from. Only drill out the plastic lm from the holes to be
used. See "Figure 3. Controller Components".
5. Secure the backplate to the box using the screws that
came with the electrical box.
2.5 Installation of the Backplate on a Flat
Wall
CAUTION
Do not expose the user interface to direct
sunlight. Too much direct sunlight will darken
the LCD screen, and it will no longer be
readable.
1. Turn off the pump at the control panel.
2. Turn off all electrical power to the pump at the main
junction box or at the circuit breaker providing electrical
power to the pump.
WARNING
ELECTRICAL SHOCK HAZARD
Turn off all switches and the main breaker in
the ePump electrical circuit before starting the
procedure. Failure to comply may cause a shock
hazard resulting in severe personal injury or death.
3. A minimum of two (2) fasteners (installer supplied)
are required when installing to a at wall to hold the
controller securely.
4. The backplate has two (2) mounting holes on the top and
bottom. By using the external mounting holes, you do
not need to remove the backplate from the controller. See
"Figure 3. Controller Components".
5. Mark the hole locations on the wall and use the fasteners
to secure the backplate to the wall.
2.6 Connection to Jandy Pro Series
variable-speed Pump
IMPORTANT
The installer must TURN ON switches 1 and 2 at the
pump when connected to the variable-speed controller.
The following steps provide the procedure for installing
the controller to a Jandy
®
variable speed pump.
1. Turn off all switches and the main breaker that
supplies power to the pump.
2. Disassemble JEP-R controller from the backplate
by removing the six screws.
See "Figure 3.
Controller Components".
WARNING
ELECTRICAL SHOCK HAZARD
Turn off all switches and the main breaker in
the ePump electrical circuit before starting the
procedure. Failure to comply may cause a shock
hazard resulting in severe personal injury or death.
3. Remove the cover of the pump junction box.
4. Feed the RS-485 cable into the tting.
PAGE 8
JEP-R Variable-Speed Pump Controller
|
Installation Manual
ENGLISH
