Janome JR3203N-BC User Manual

Specifications
Desktop Robot JR3000
Settable Items
Setting/Selection Range
Function
Version Number
1
2
Compatible with two CC-Link versions: Ver.1
and Ver.2.
Stations
Occupied/Expansion
Cyclic Settings
1 Station Occupied /
Expansion Cyclic Setting x1
2 Stations Occupied /
Expansion Cyclic Setting x1
3 Stations Occupied /
Expansion Cyclic Setting x1
4 Stations Occupied /
Expansion Cyclic Setting x1
1 Station Occupied /
Expansion Cyclic Setting x2
2 Stations Occupied /
Expansion Cyclic Setting x2
1 Station Occupied /
Expansion Cyclic Setting x4
1 Station Occupied /
Expansion Cyclic Setting x8
Word number input and word number output
are decided the same as the tables below
depending on the settings for the occupied
stations and the expansion cyclic settings.
NOTE
Expansion cyclic settings 2, 4, 8 are only
compatible with Ver. 2.
1 Station Occupied/Expansion Cyclic Setting x1
Score
Register Number
Relay Number
Data Input
4
100 – 103
-
I/O Input
16
-
1400 – 140F
Data Output
3
180 – 182
-
I/O Output
16
-
1C00 – 1C0F
2 Stations Occupied/Expansion Cyclic Setting x1
Score
Register Number
Relay Number
Data Input
8
100 – 107
-
I/O Input
32
-
1400 – 141F
Data Output
7
180 – 186
-
I/O Output
32
-
1C00 – 1C1F
3 Stations Occupied/Expansion Cyclic Setting x1
Score
Register Number
Relay Number
Data Input
12
100 – 10B
-
I/O Input
48
-
1400 – 142F
Data Output
11
180 – 18A
-
I/O Output
48
-
1C00 – 1C2F
4 Stations Occupied/Expansion Cyclic Setting x1
Score
Register Number
Relay Number
Data Input
16
100 – 10F
-
I/O Input
64
-
1400 – 143F
Data Output
15
180 – 18E
-
I/O Output
64
-
1C00 – 1C3F
