19
Amplifier/Subwoofer PSW-D112/DPS-12
PSW-D112/DPS-12 MECHANICAL PARTS LIST
Ref. # Part Number Description Qty
PSW-D112/DPS-12
1 70302 Knob, 3 pcs on DPS-12, 2 pcs on PSW-D112
2 70312 Faceplate PSW-D112
2 70311 Faceplate DPS-12
3 70316 Amp PCB support
4 70150 Phase switch 1
(also DPS-12 Video Contour switch)
5 70151 Power switch Safety part
6 70170 #4x0.5" Screws to secure input jack
7 70171 #10 x 1" Screw machine screw
Bolts for transformer 4 per unit
8 70172 #10 keps Nuts for transformer 4 per unit 4
9 70173 #6 x 0.5" Screws for fuse PCB 2per unit 2
10 80116 Transformer #4632 Safety part 1
11 80117 250V, 2.0A, T type SLO BLO fuse Safety part
12 80118 Preamp board, D112,D115,DPS12 Safety part
13 80119 Power amp board D112, D115,DPS12
Safety part
14 80120 High level input PCB D112,D115,DPS12
Safety part
15 108116 High level 5way binding post(pr) (4) or (6)
16 108322 Six line RCA input jack (Rev0) 1
108321 Quad RCA input jack (Rev1) 1
17 108323 Single RCA input jack (Rev0 version only) 1
To Next Page
