OPERATION
Crossover Adjustments
High-Pass Control
If you hooked up your subwoofer as shown in Speaker
Connection 4 on page 9. you also have the capability of
adjusting the high-pass frequency. The High-Pass control
determines the frequency at which the main speaker will
start reproducing sounds. If your main speakers can
comfortably reproduce some low-frequency sounds, also
set this control to a lower frequency setting, between 50Hz –
100Hz. This will concentrate the subwoofer’s efforts to the
ultradeep bass sounds, while your main speakers continue
to reproduce the mid-bass information. If you are using
smaller bookshelf speakers that do not extend to the lower
bass frequencies, set the high-pass crossover control to a
higher setting, between 125Hz – 180Hz. With this setting,
your main speakers will not have the burden of reproducing
any low-frequency sounds.
If you hooked up your subwoofer as shown in Speaker
Connection 1 on page 8, the high-pass frequency is fixed at
150Hz.
If you hooked up your subwoofer as shown in Speaker
Connection 2 or 3 on page 8 and 9, no high-pass control
adjustment can be made from the subwoofer. Unless you
receiver/amplifier incorporates a high-pass crossover, your
main speakers will continue to get a full-range signal.
Final adjustment and blending of the low-pass and
high-pass controls may evolve over several listening
sessions. A good starting point would be to set both the low-
and high-pass controls to the same frequency and adjust
from that point.
Low-Pass Control
The Low-Pass control determines the highest frequency at
which the subwoofer reproduces sounds. If your main
speakers can comfortably reproduce some low-frequency
sounds, set this control to a lower frequency setting,
between 50Hz – 100Hz. This will concentrate the
subwoofer’s efforts on the ultradeep bass sounds required
by today’s films and music. If you are using smaller
bookshelf speakers that do not extend to the lower bass
frequencies, set the low-pass crossover control to a higher
setting, between 120Hz – 180Hz.
Phase
Phase Control
The Phase Control determines whether the subwoofer
speaker’s piston-like action moves in and out with the main
speakers, 0° , or opposite the main speakers, 180° . There is
no correct or incorrect setting. Proper phase adjustment
depends on several variables such as room size, subwoofer
placement and listener position. Adjust the phase switch to
maximize bass output at the listening position.
Remember, every system, room and listener is different.
There are no right or wrong settings; any setting you choose
will result in excellent performance. Should you decide to
fine-tune your system for optimum performance, be patient
and trust your ears. It will be worth the effort involved to fully
“tweak” your system.
7
Amplifier/Subwoofer PSW-D112/DPS-12
