VTX A8 | User Manual
14.2 - VTX B18
SYSTEM
Frequency Range (-10 dB):
28 Hz - 80 Hz (Preset: VTX B18 80)
Coverage Pattern Options
1
:
Omni-directional or Cardioid
System Input Power Rating
2
:
1300W Continuous (IEC/100 hour)
Maximum Peak Output
3
:
135dB (Preset: VTX B18 80)
System Amplification:
Crown Audio I-Tech 12000HD
Crown Audio I-Tech 4x3500HD
Required Amplifier Channels:
1-channel
Number of Cabinets per Circuit
IT-12000HD:
IT-4x3500HD:
2 x VTX B18
1 x VTX B18
System Impedance
4
:
8 ohms
TRANSDUCERS
Low Frequency :
1 x JBL 2288H, 18in diameter, dual 4in diameter voice coil, neodymium Differential Drive
ENCLOSURE
Construction :
18mm and 15mm ,11-ply Baltic birch plywood, Black DuraFlex
TM
finish, integral recessed handles
IP Rating
5
:
IP55 (IEC 60529)
Suspension :
Captive suspension plates, quick-release pins, spring-loaded mechanism
Grill :
Powder-coated 14-guage hex-perforated steel with acoustically transparent black cloth backing
Connectors
Type :
Pin Assignments :
Neutrik® SpeakON® NL-4 (2x at the rear and 2x at the front)
Selectable between Pins 1 ± and Pins 2 ±
Dimensions (H x W x D) :
551.68mm x 761.29mm x 736.6mm
21.72in x 29.97in x 29.0in
Net Weight :
68 kg (150 lbs)
Footnotes:
1: Based on speaker preset selection and cabinet orientation/configuration.
2: IEC Standard: IEC shaped noise with 6dB crest factor based on nominal impedance and a duration of 100 hours. Continuous is defined as 2x RMS.
3: Peak, unweighted SPL, measured under half-space conditions at 1 meter using broadband pink noise with a 12dB crest factor and specified preset.
4: Nominal impedance within the stated frequency range of the product. Minimum impedance is 5.6Ω is 150Hz.
5: Front face at 0 degree or greater down angle to allow the cabinet to drain water. Suspension components fully weather rated for indoor or covered outdoor conditions where humidity is nominally under 50% and not local
to bodies of corrosive materials.
JBL continually engages in research related to product improvement. Some materials, production methods and design refinements are introduced into existing products without notice as a routine expression of that
philosophy. For this reason, any current JBL product may differ in some respect from its published description, but will always equal or exceed the original design specifications unless otherwise stated.
