Operation
Working with the Machine
126 126
9811/9950-1
Lifting With the Excavator
!MWARNING
You must turn on the overload warning system before
you use the excavator for object handling, or a
stability hazard could occur.
8-2-8-20
Lifting operations must be carried out with the overload
warning system turned ON, K
Overload Warning
System (If fitted) ( T 96).
Note: Use a signalman when lifting with the excavator.
Make sure you both understand and use the recognized
signals. Keep all persons clear of the load and machine
while the load is on the excavator.
1 A bucket should be fitted when lifting with the
excavator to prevent the link swinging. Check that the
load is not greater than the safe working load for the
bucket.
T033970-2
Fig 57.
2 The correct JCB lifting shackle A must be fitted. The
bucket ram must be fully extended as at B. If your
machine is not fitted with this equipment there will be
A
B
C
