jcb 8026 CTS User Manual

Optional Attachments
Quickhitch Rockbreaker
281 281
9811/9950-1
Installing a Quickhitch Rockbreaker
!MCAUTION
When the Quick-Hitch is installed and its attachment
fitted, there is a danger of the attachment hitting the
underside of the boom. Operate the boom and dipper
carefully when the Quick-Hitch and its attachment are
fitted.
2-4-4-2
1 Position the breaker.
Set the bucket on firm level ground. Use safe and
correct lifting equipment to move bucket
e Position the machine
f Use the excavator controls to engage the jaw of
the Quickhitch with the pivot pin of the breaker.
g Use the excavator controls to roll the Quickhitch in
until the latch hook has fully engaged the pivot pin
on the breaker. It may be necessary to apply a
load on the bucket teeth to achieve Quickhitch
connection.
Alternatively, use the tommy bar to lever the latch
off, allowing the breaker pivot pin to locate in jaw
of the Quickhitch.
!MCAUTION
Make sure that the latch hook has fully engaged.
2-4-4-3
h Fit the latch hook locking pin and secure with
lynch pin.
