Operation
Drive Controls, Switches and Instruments
67 67
9811/9950-1
Driving the Machine
!MDANGER
Drive Safely
Drive the machine smoothly. Spin turn manoeuvres,
zig-zag driving or turning too fast can cause the
vehicle to overturn.
8-1-2-2_2
!MWARNING
When the cab is swung around so that it is facing the
track motor end of the undercarriage, the action of the
tracking controls is reversed. Take extra care!
8-2-8-1
731911-5
Fig 22. Moving the Machine Forward or Backward
To move the machine forward, push both levers forward
(Direction F). Release the levers to stop.
To move the machine backward, pull both levers backward
(Direction R). Release the levers to stop.
F
R
