Operation
Instruments
40 9831/0650-3 40
Icon Fault Description
Oil Filter Maintenance Alarm Maintenance due for oil filter.
Air Filter Maintenance Alarm Maintenance due for air filter.
Fuel Filter Maintenance Alarm Maintenance due for fuel filter.
Viewing The Instrument Pages
Navigation Menu
To enter the navigation menu, press both the UP and DOWN buttons simultaneously.
Figure 22.
To select the required icon, press the UP button to cycle right or the DOWN button to cycle left until the desired
instrumentation section is reached.
Figure 23.
Once the desired icon is at the top, press the AUTO Mode button to enter that instrumentation section.
If the AUTO mode button is not pressed, the display automatically returns to the HOME PAGE after the
configured setting of the LCD Scroll Timer.
