Travel Equipment
Motor Fixed displacement piston motor (automatic 2-speed change)
Suction Capacity 164.4/98.1 cc/rev
Working Pressure 350 kgf/cm
2
(343 bar, 4977 lb/in
2
)
Working Flow 211 litre/min (46.4 UK UK gal)
Reduction Gears
Deceleration Ratio 44.384
Parking Brake
Brake Torque 2135 kgf/m (20.9 kNm, 15436 ft/lb) including reduction gear
Brake Pressure Release > 14 kgf/cm
2
(13.5 bar, 199 lb/in
2
)
Brake valve pressure relief 360 kgf/cm
2
(353 bar, 5119 lb/in
2
) at 40 litre/min (8.8 UK gal)
Dry Weight 270 kg (595 lb)
Boom Rams
Cylinder Inside Diameter 130 mm
Rod Diameter 90 mm
Max Contracted Length 1843 mm
Stroke 1278 mm
Dry Weight 214 kg (472 lb)
Dipper Ram
Cylinder Inside Diameter 150 mm
Rod Diameter 105 mm
Max Contracted Length 2234 mm
Stroke 1632 mm
Dry Weight 341 kg (752 lb)
Bucket Ram
Cylinder Inside Diameter 135 mm
Rod Diameter 90 mm
Max Contracted Length 1687 mm
Stroke 1073 mm
Dry Weight 211 kg (465 lb)
1 - 4
Section E
Hydraulics
9803/6400
Section E
1 - 4
Issue 2*
Technical Data JS240/260 and Variants
*
*
*
*
*
*
*
