76 - 1
Section E
Hydraulics
9803/6400
Section E
76 - 1
Issue 2*
Hydraulic Rams
Reconditioning
Structure and Characteristics of Special Jigs for Repair of Rams
Inserting seal ring and correction jig.
a. Jig components
Note: For the above Part No. the tube diameter is 120 mm.
b. Special characteristics
Because the seal ring is hard, it requires a lot of time to insert it without a special jig. By using the special jig, anyone can insert
the seal ring on the piston quickly, easily and accurately without damaging the seal ring.
Bushing removal jig
a. Jig components
Note: For the above Part No. the tube diameter is 120 mm.
b. Special characteristics
Because the bushing is press-fitted by the hydraulic press at the central part of the cylinder head, it requires a lot of time and
work in order to remove the bushing from the cylinder head quickly, easily and accurately without damaging the inside of the
cylinder head.
Part no Part Name Qty Note
WDB 2052 Seal ring inserting and correction jig set 1
Inner Guide (1)
Outer Guide (1)
Plate (1)
Collection (1)
Part no Part Name Qty Note
WDB 2166 Jig set for pulling out bushing 1 Also to be used for press-fitting bushing
Chuck assembly 1
WDB 2166-1 Retainer 1 Also to be used for press-fitting wiper ring
Block 1 Prepare locally
Lever 1 Prepare locally
Allen wrench 1
*
*
To Next Page
