2) Use a check program function.
（
DDL-9000C-S
）
① No.01 Selection of a machine head
(Caution) 1. Do not use this function.
2. When you use this function, data on a memory switch is initialized. Be careful about it.
①-1. Press the ❷ to select the
machine type.
The machine type that can be select-
ed is as follows:
Machine type Display Machine type Display
For Standard materials
(For general export)
For Standard materials
(For CE)
For heavy-weight materials
(For general export)
For heavy-weight materials
(For CE)
①-2. Execute or cancel a change in the machine types.
1 By pressing the ❺, the screen giving you instructions to turn off the sewing machine is dis-
played after execution of a change in the machine types. Turn off the machine.
2. After you turn on the sewing machine again, the machine starts as a selected machine type
3. By pressing the ❻, the current screen returns to the check program selection screen after
cancellation of a change in the machine types.
②No.02 Z-phase adjustment ..................................... Refer to "3-.(7)-1) Z-phase adjustment of a main
motor"
③
No.03 Adjustment of a presser lifter motor
............. Refer to "3-.(7)-2) Adjustment of the origin of a presser
lifter motor"
④No.04 Pitch motor adjustment ............................... Refer to "3-.(7)-3) Pitch motor adjustment"
⑤No.05 Vertical feed motor adjustment................... Refer to "3-.(7)-4) Vertical feed motor adjustment"
⑥No.06 Vertical feed link adjustment....................... Refer to "3-.(7)-5) Vertical feed link adjustment"
❷
❻
❺
– 89 –
