Adjustment Procedure
Results of Improper Adjustment
Conguration of lubrication mechanism parts is as shown in the
drawing.
1. Oil tank
Pull up the oil tank ❶ straight from the oat case guide ❷ to
take it out.
Remove and adjust the lubrication pipe ❸ and others within the
permissible range where they can be stretched.
The oat case guide ❷ has a notch groove with orientation.
Push it straight along the groove to make a joint.
(Push it until there is a feeling of coupling with a click sound.)
2. Float
The oat ❹ has an orientation.
Insert it in the oil tank ❶ with its at plane positioned on the right
as seen from worker side.
Be careful not to bend the bar of the oat ❹.
Description
Part No.
Float
❹
40172430
3. Float case guide
Put the oat case guide ❷ in the guide groove section of the
peep window ❺ and x it to the bed.
4. Peep window
Remove the window plate located behind the arm. It is xed to
the arm.
5. Oil lter
The oil lter ❻ can be cleaned after removing the lubrication
pipe xing ring ❼ and pulling out the lubrication pipe ❸.
* When you disassemble it, remove two setscrews for an oil tank
and put it out downward. It is removed by unit in such a state as
shown in the Figure B
– 145 –
