Adjustment Procedure Results of Improper Adjustment
1. Hold the bobbin so that it turns to the right and insert it in the
bobbin case. (See Drawing.)
2. Pass the thread through the threading port A of the bobbin
case. When the thread is pulled in the direction of B, it can be
pulled toward the threading port C passing beneath the thread
tension spring.
3. Examine if the bobbin turns in the direction of the arrow when
the bobbin thread is pulled.
◦ If the direction of clockwise
winding is adopted, variation is
lessened possibly caused by a
change in the amount of bobbin
thread.
About the standard part numbers（DDL-9000C-□□）
Part name S type H type
Bobbin case D1837555BAAA 40000264
Bobbin case with idling
prevention spring
D1837555BOBA 11038700
Bobbin 40091141
(Made of aluminum)
B9117012000
(Made of iron)
1) Bobbin case with idling prevention spring
The DDL-9000C Series employs the bobbin case with an idling prevention spring.
Adjustments of idling prevention spring tension can be carried out in the procedures below.
If bobbin idling occurs, increase the idling prevention spring tension
When the bobbin runs idle
→
Increase the tension of the idle-prevention spring.
When the thread is not well tightened
→
Decrease the tension of the idle-prevention spring.
* Adjustment of idling prevention spring tension
(1) Insert an old needle as illustrated and remove the spring by lifting it up.
(Suggestion: Use the thumb to prevent the spring from popping out.)
(2) The spring tension can be changed by changing the height of the arch-shaped section of the spring.
(Make sure not to permit the free end of the spring to come out of the bobbin case.)
(3) Firstly, set the ear ❶ and insert the needle. Then, settle the ear ❷ is the state that the center part of
the spring is lifted.
(4) When a bobbin case with an idling prevention spring is used, it should be inserted in the winding
direction as illustrated.
(Unevenness in sewing at high or low speed)
When sewing seems to be too tight
at low speed:
→
Adjust the bobbin thread tension and the idling
prevention spring tension to be strengthened.
When sewing seems to be too
weak at low speed:
→
Adjust the bobbin thread tension and the idling
prevention spring tension to be weakened.
* If there is a problem of bobbin idling or uneven sewing at high or low speed, use of a bobbin case with
an idling prevention spring is effective.
– 11 –
