Adjustment Procedure
6)-2. DDL-9000F-S
Correction Remarks
Forward pitch K330
* The pitch is corrected considering the present value as 100%.
* Aim at 100% adjustment of the pitch against forward reverse 100% and a
numerical value displayed on the operation panel.
Reverse pitch K331
1. Press ❾ on the sewing screen to display
the mode screen.
2. After selection of the "01 Memory switch", and
selection of the "1. Display All".
3. After selection of the "K330 Forword stitching
pitch correction" and "K331 Reverse stitching
pitch correction" to perform a pitch correction.
* After adjustment, there may be a gap in the dis-
play of a scale and in a needle-entry, depending
on the sewing products.
In this case, adjust it with the scale displayed
on the panel
– 35 –
