– 13 –
1
Winding the bobbin
Installing the thread guide.
Positioning latches
Bobbin winding shaft
Bobbin presser
Thread guide base
❺
❷
❶
Thread trimmer retaining plate
❸
❹
CAUTION
Turn OFF the power switch.
spool cap
in place
Bobbin winder
side anchor
Spool holder
disk
Thread stand
thread guide
Bobbin winder
❶
Raise the bobbin winder fully, turning slightly until the positioning latches engage.
❷
Set the large spool over the bobbin winder side anchor
.
❸
Set the household-type thread onto the spool holder disk and then insert a spool cap in place.
❹
To set a large-diameter spool, set the bobbin winder side anchor upside down to stabilize the spool.
❺
Pass the thread coming from the spool on the thread guide pin (rod) just above the spool.
To Next Page
