– 7 –
1. Thread trimmer retaining plate
2. Thread guide base
3. Presser foot pressure regulator
4. Thread tension dial
5. Lamp (built-in type)
6. Hand pulley
7. Bobbin winder
8. Spool holder disk
9. Bobbin winder side anchor
10. Bobbin presser
11. Bobbin winding shaft
12. Power switch
13. Inlet of electric power cord
14. Presser foot lifting lever
15. Thread guide pin
16. Eye protection cover
17. Tension controller No. 1
18. Hand wheel
19. Presser regulator cover
20. Stitch regulator connection connector
21. Panel junction cable connection connector
22. Hook cover
23. Connecting plate (large)
24. Connecting plate (small)
Principal Parts
1. Screw in the presser foot
2. Presser foot
3. Throat plate
4. Needle clamp
5. Needle bar thread hook
6. Needle
7. Needle bar thread guide
5
3
6
4
2
1
2
3
7
8
11
10
1
6
18
9
4
5
12
13
15
16
17
7
21
20
19
14
24
23
22
