KE2000 Installation Manual

3-2. Safety cover

Peel off the filament tapes stuck on the safety cover.

Fig ３－２－１

Filament tapes

Safety cover R

Safety cover F

Main unit

Default Chapter3
- Table of Contents3
1 Basic Configuration and Name of each Part5
- Ke-2010/2020/20405
- Ke-20306
2 Installing the Main Unit7
3 Detaching the Packing Materials from the Machine8
4 Adjusting the Transport Height and Leveling the Machine14
- Ke-2010/2020/204014
- Ke-203017
5 X-Y Unit19
- Detaching the X-Axis Frame Fixing Parts (for Model 2030 Only)19
- Detaching the Head Fixing Parts20
6 Head Unit21
- Detaching the Packing Materials21
- Detaching the Head Unit Fixing Parts22
7 Board Transport Unit24
8 ATC Unit27
9 CAL Block27
10 Connecting the Compressed Air Tube29
11 Connecting the Power Cord32
12 Mounting the Accessories34
13 Interface with External Equipment38
- Ke-2020/204038
- Ke-2010/203040
14 Connecting the Matrix Tray Changer (MTC)42
15 Checking the Machine before Turning on the Power47
16 Adjusting the Height of the Overall Feeder Exchange Trolley (Optional)48
