ENGLISH
– 21 –
* Do not change the set values with asterisk (*) mark as they are functions for maintenance. If the standard set value set at the
time of delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated.
If it is necessary to change the set value, please purchase the Engineer’s Manual and follow the instructions.
(Descriptions of setting in this list are the standard values at the time of delivery.)
However, contents of function setting are subject to change for improvement of function and performance without notice.
No Item Description Setting range Indication of function setting
Ref.
page
29
Suction time of
the rst start of
the back solenoid
This function sets the suction motion time of the back-tack solenoid.
50 ms to 500 ms
50 to 500
(ms)
2 9 2 5 0
30
30
Function of reverse
feed stitching on the
way
Function of reverse feed stitching on the way
0 : Function of reverse stitching on the way is not operative.
1 : Function of reverse feed stitching on the way is operative.
0/1
3 0 0
31
31
Number of stitches of
reverse feed stitching
on the way
Number of stitches of reverse feed stitching on the way.
0 to 19
(Stitches)
3 1 4
31
32
Effective condition of
reverse feed stitching
on the way when the
sewing machine is
stopping.
Effective condition of reverse feed stitching on the way
0 : Function is not operative when the sewing machine stops.
1 : Function is operative when the sewing machine stops.
0/1
3 2 0
31
33
Thread trim-
ming function
by reverse feed
stitching on the
way
Thread trimming function by reverse feed stitching on the way
0 :
Automatic thread trimming function after completion of reverse
feed stitching on the way is not operative.
1 : Automatic thread trimming after completion of reverse feed
stitching on the way is performed.
0/1
3 3 0
31
*
35
Number of
rotation at a low
speed
Lowest speed by pedal
150 to 250
(r.p.m.)
3 5 1 7 0
37
Number of rota-
tion of soft-start
Sewing speed at the start of sewing (soft-start)(The max. value
depends on the number of rotation of the sewing machine head.)
100 to MAX
(r.p.m.)
3 7 1 7 0
24
38
One-shot speed One-shot speed (The max. value depends on the number of rotation
of the sewing machine head.)
150 to MAX
(r.p.m.)
3 8 1 5 0 0
32
*
39
Pedal stroke at the
start of rotation
Position where the sewing machine starts rotating from pedal neutral
position (Pedal stroke)
10 to 50
(0.1 mm)
3 9 3 0
*
40
Low speed sec-
tion of pedal
Position where the sewing machine starts accelerating from pedal
neutral position (Pedal stroke)
10 to 100
(0.1 mm)
4 0 6 0
*
41
Starting position
of lifting presser
foot by pedal
Position where the cloth presser starts lifting from pedal neutral
position (Pedal stroke)
–60 to –10
(0.1mm)
4 1 – 2 1
*
42
Starting position
of lowering
presser foot
Starting position of lowering presser foot
Stroke from the neutral position
8 to 50
(0.1 mm)
4 2 1 0
*
43
Pedal stroke 2 for
starting thread
trimming
Position 2 where the thread trimming starts from pedal neutral
position (When the function of lifting presser foot by pedal is
provided.) (Pedal stroke)
–60 to –10
(0.1 mm)
4 3 – 5 1
*
44
Pedal stroke
for reaching the
maximum number
of rotation
Position where the sewing machin reaches its highest sewing speed
from pedal neutral position (Pedal stroke)
10 to 150
(0.1 mm)
4 4 1 5 0
*
45
Compensation of
neutral point of the
pedal
Compensation value of the pedal sensor
–15 to 15
4 5 0
47
Holding time of
lifting auto-lifter
Limitation time of waiting for lifting solenoid type auto-lifter device
10 to 600
(second)
4 7 6 0
32
*
48
Pedal stroke
1 for starting
thread trimming
Position where thread trimming starts from pedal neutral position
(Standard pedal) (Pedal stroke)
–60 to –10
(0.1 mm)
4 8 – 3 5
49 Presser lowering
time
Presser lowering time from depressing the pedal
0 to 250 (ms)
0 to 250
(
10ms)
4 9 1 4 0
32
51 Compensation of
solenoid-on timing
of reverse feed
stitching at the
start of sewing
Compensation of starting the solenoid for reverse feed stitching when
reverse feed stitching at the start of sewing is performed.
–36 to 36
(10˚)
5 1 2 5
33
52 Compensation of
solenoid-off timing
of reverse feed
stitching at the
start of sewing
Compensation of releasing the solenoid for reverse feed stitching
when reverse feed stitching at the start of sewing is performed.
–36 to 36
(10˚)
5 2 – 7
33
