JUKI SC-510 User Manual

－
36
－
#3
2-pitch initial output selection (Function setting No. 102)
Whether 2-pitch output at the time of turning ON the power is to be "ON" or "OFF" can be set.
0 : Output ON
1 : Output OFF
2 : It is returned to the state immediately before turning OFF the power.
#2
Inversion of 2-pitch output during outputting alternate vertical amount (Function setting No. 101)
State of 2-pitch output synchronizing with alternate vertical output is inversed and outputted.
When 2-pitch output is "ON" at the time of changeover of alternate vertical output, the output is changed
over to "OFF" and in case of "OFF", to "ON".
0 : Function OFF
1 : Function ON
2
1
01
1
0
01
#4
Number of stitches of automatic release of alternate vertical output setting
(Function
setting No. 103)
Release of alternate vertical output is automatically performed by number of stitches.
(0 : Automatic release is invalid.)
Set the output to "OFF" after setting number of stitches of alternate vertical output.
When "0" is set, this function does not work. (Stitches become, however, more than the number of stitch-
es that has been set.)
#5
Selection of up-position of automatic presser lifting at the time of reverse revolution to lift needle
of thread trimming (Function setting No. 104)
Selection of automatic presser lifting timing at up-position at the time of reverse revolution to lift needle of
thread trimming
By making this setting "ON", the presser is lifted to up-position after thread trimming and the reverse revo-
lution to lift needle motion is performed.
At the time of "OFF", the presser is lifted after the reverse revolution to lift needle.
#6
Needle cooler output OFF delay time (Function setting No. 105)
Delay time from the stop of the sewing machine to output OFF is set with the needle cooler output function. Needle cooler
output continues “ON” as long as this setting time from the stop of the sewing machine.
Note) This function is valid only when setting Function No. “13” Needle cooler output of the optional output function setting.
#7
Selection of alternate vertical output after thread trimming (Function setting No. 107)
Alternate vertical output is forcibly set to ON or OFF after thread trimming.
In case of the invalid setting, alternate vertical output maintains the state before thread trimming. In case of the set value is
“1”, alternate vertical output becomes the state of “OFF” and in case of “2”, the output becomes “ON”.
0 : Automatic release is invalid
1 : 1 to 30 (1 stitch)
3
0
01
0 : Selection of up-position is not performed.
1 : Automatic presser lifting at up-position is performed.
4
0
01
0 to 2000ms (100ms)
5
5 0 0
01
0 : Invalid
1 : OFF
2 : ON
7
0
01
#8
Selection of needle thread clamp switch function (Function setting No. 109)
Needle thread clamp switch function of LU-2220 machine head is selected. (When No.93 is "2" or "3",
however, the motion become invalid.)
0 : Needle thread clamp motion is invalid.
1 : On/Off with the motion valid switch
2 : Forcibly valid
9
0
01
#9
Setting of brake starting angle at the time of thread trimming up-position stop (Function setting No. 112)
This function sets the brake starting angle at the time of thread trimming up-position stop.
Setting range (0 : Up-detection start)
0
to10˚
2
0
11
