CONTENTS
[1] SPECIFICATIONS OF TL-2010Q/2000Q
i
....................................................... 1
[2] NAMES OF COMPONENTS ........................................................................... 3
[3] DISASSEMBLY AND ASSEMBLY .................................................................. 3
[4] PRINTED CIRCUIT BOARD DIAGRAM (CONNECTOR LAYOUT) ............. 15
[5] ADJUSTMENTS OF COMPONENTS ........................................................... 16
WARNING :
To avoid the risk of re, electric shock, injury to persons or damage to components, especially keep the
following :
• When disassembling, assembling or adjusting the sewing machine, remove the power plug.
• When assembling, be careful about the electrical cord being caught with other components,
damage to the covered parts of the cord or miswiring.
• When replacing the part(s), use the genuine part(s).
To Next Page
