JUKI TL-2200QVP User Manual

5
3
6
4
2
1
7
2
3
7
8
11
10
1
6
18
9
4
5
12
13
14
15
16
17
21
20
19
22
24
23
–
12 –
Principal Parts
1. Thread trimmer retaining plate
2. Bobbin winder guide
3. Presser foot pressure regulator
4. Thread tension dial
5. Lamp (built-in type)
6. Hand pulley
7. Support rod
8. Spool pin
9. Anti vibration cone
10. Bobbin presser
11. Bobbin thread winding shaft
12. Power switch
13. Inlet of electric power cord
14. Presser foot lifting lever
15. Thread guide pin
16. Eye protection cover
17. Tension controller No. 1
18. Hand wheel
19. Presser regulator cover
20. Stitch regulator connec tion connector
21. Panel junction cable connection connector
22. Hook cover
23. Connecting plate (large)
24. Connecting plate (small)
1. Screw in the presser foot
2. Presser foot
3. Throat plate
4. Needle clamp
5. Needle bar thread hook
6. Needle
7. Needle bar thread guide

JUKI TL-2200QVP Specifications

General

Thread Tension	Manual
Lighting	LED
Needle Position	Up/Down
Automatic Needle Threader	Yes
Bobbin Winder	Built-in
Thread Tension Control	Manual
Needle Bar Stroke	35mm
Stitching Speed	1500 stitches per minute
Stitch Length	Maximum 6mm
Motor	AC Motor
