25 –
Attaching the needle
1. Turn OFF the power switch.
2. Lower the presser foot.
3. Move the needle bar up to the highest position of
its stroke.
4. Holding a needle with its long groove faced to the
left, insert the needle into the needle bar until it
will go no further. Then, tighten the needle clamp
screw.
Checking the needle
Attaching the needle
Needle clamp screw
Tightens
Loosens
Scarf
Needle with
a round shank
Face the long groove on the needle to the left
Flat plate
Parallel
● Check the needle for its straightness occasionally. Any defective needle
would cause needle breakage, stitch skipping, thread breakage or
damage to materials.
1. Remove two setscrews
2 and 3 from LED cover 1. Then, the
LED cover can be lowered.
2. Rip off the stained masking seal. Put new masking seal 4 in
place.
■ Replacing the masking seal
Turn OFF the power switch.
Always must be disconnected plug from socket-outlet.
CAUTION
Maintenance
Turn OFF the power switch.
CAUTION
To Next Page
