5
2
1
3
4
–
18 –
Winding the bobbin
Bobbin winder guide
Positioning latches
Bobbin presser
Bobbin thread winding shaft
Thread trimmer retaining plate
1
Installing the thread guide.
1 Raise the support rod fully, turning slightly until the positioning latches engage.
2 Set the large spool over the anti vibration cone.
3 Set the household-type thread onto the spool pin and then insert a spool cap in place.
4 To set a large-diameter spool, set the anti vibration cone upside down to stabilize the spool.
5 Pass the thread coming from the spool on the thread guide pin (rod) just above the spool.
Turn OFF the power switch.
CAUTION
