JUKI TL-2200QVP User Manual

3
4
5
1
2
3
2
–
19 –
■ Take out the bobbin case.
Bring up the needle. Open the hook cover. Take out the bobbin case.
■ Thread the bobbin winder guide.
■ Take out the bobbin from the bobbin case.
Snap in the latch to let the bobbin come out of the bobbin case.
■ Installing the bobbin.
1 Wind thread on the bobbin clockwise by several turns.
2 Place the bobbin on the bobbin thread winding shaft.
3 Press the bobbin presser.
Thread is automatically wound on the bobbin.
Turn OFF the power switch.
CAUTION

JUKI TL-2200QVP Specifications

General

Thread Tension	Manual
Lighting	LED
Needle Position	Up/Down
Automatic Needle Threader	Yes
Bobbin Winder	Built-in
Thread Tension Control	Manual
Needle Bar Stroke	35mm
Stitching Speed	1500 stitches per minute
Stitch Length	Maximum 6mm
Motor	AC Motor
