Juniper J-series Services Router J2320 User Manual

CAUTION: Do not install a combination of PIMs in a single chassis that exceeds the
maximum power and heat capacity of the chassis. If J-series power management is
enabled, PIMs that exceed the maximum power and heat capacity remain offline
when the chassis is powered on.
On each J-series Services Router with Avaya VoIP, a single TGM550 Telephony
Gateway Module (TGM) and at least one telephony interface module (TIM) is required.
No more than four TIMs of any kind can be installed on a single chassis.
Table 34: J2320 and J2350 Avaya VoIP Module Summary
Sample Interface
Name
(type-pim/0/port)
Maximum Number on
a Chassis
Slot and Port
Numbering
Software Release for
This PIMAlso CalledPIM
vp-3/0/0
(See the interface
naming conventions
in the J-series Services
Router Basic LAN and
WAN Access
Configuration Guide.)
One (required)
If more than one
TGM550 is installed,
only the one in the
lowest-numbered slot
is enabled. For
example, if TGM550s
are installed in slots 2
and 3, only the one in
slot 2 is enabled.
■
J2320—Slots
1 through 3
■
J2350—Slots
1 through 5
JUNOS 8.4 and later
■
TGM550
Gateway
Module
■
TGM550
TGM550
Telephony
Gateway
Module
–Two
■
J2320—Slots
1 through 3
■
J2350—Slots
1 through 5
JUNOS 8.4 and later
■
TIM510
E1/T1 media
module
■
TIM510
TIM510 E1/T1
Telephony
Interface
Module
–Two
■
J2320—Slots
1 through 3
■
J2350—Slots
1 through 5
JUNOS 8.4 and later
■
TIM514
analog media
module
■
TIM514
TIM514
Analog
Telephony
Interface
Module
–Two
■
J2320—Slots
1 through 3
■
J2350—Slots
1 through 5
JUNOS 8.4 and later
■
TIM521 BRI
media
module
■
TIM521
TIM521 BRI
Telephony
Interface
Module
68 ■ Avaya VoIP Modules
J2320, J2350, J4350, and J6350 Services Router Getting Started Guide
