Juniper SRX320 Quick Start Guide

Figure 2: Rear Panel Components of SRX320
NOTE: Check the parts in the shipment against the items on the packing list. If anything is missing or damaged,
contact your Juniper Networks customer service representative.
Specifications
SRX320-PoESRX320Specification
7.52 in. x 11.81 in. x 1.73 in.
(19.10 cm x 29.99 cm x 4.39 cm)
7.52 in. x 11.81 in. x 1.73 in.
(19.10 cm x 29.99 cm x 4.39 cm)
Dimensions (D x W x H)
3.4 lb (1.54 kg)3.28 lb (1.49 kg)Chassis weight
221 W46 WAverage power consumption
755 BTU/hr157 BTU/hrAverage heat dissipation
5% to 90%, noncondensing5% to 90%, noncondensingRelative humidity
Factory-Default Settings
The SRX320 device is shipped with the following factory-default settings:
Table 1: Security Policies
Policy ActionDestination ZoneSource Zone
permittrusttrust
permituntrusttrust
3

Juniper SRX320 Specifications

General

Firewall throughput	1000 Mbit/s
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	27 W
Heat dissipation	157 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	284700 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2

Weight and Dimensions

Weight	1510 g
Dimensions (WxDxH)	299.9 x 43.9 x 191 mm
