Juniper SRX320 Quick Start Guide

Figure 5: Securing the Chassis to the Rack
g000951
5. Check that the mounting brackets on each side of the rack are lined up with each other.
The SRX320 Services Gateway can also be mounted on a desk or a wall. For details, see the SRX320 Services Gateway
Hardware Guide.
Connect the Grounding Cable (Optional)
1. Attach an ESD strap to an ESD point and place the other end of the strap around your bare wrist.
2. Connect the grounding cable to a proper earth ground.
3. Place the grounding cable lug over the grounding point on the rear of the chassis.
NOTE: A licensed electrician must attach a cable lug to the grounding cable. A cable with an incorrectly
attached lug can damage the device.
4. Secure the grounding cable lug to the grounding point with the screw.
7

Juniper SRX320 Specifications

General

Firewall throughput	1000 Mbit/s
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	27 W
Heat dissipation	157 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	284700 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2

Weight and Dimensions

Weight	1510 g
Dimensions (WxDxH)	299.9 x 43.9 x 191 mm
