AV-27D502

No. 51797C 35

! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local

RESISTOR

R1856 QRX039J-6R8 MF R 6.8Ø 3W J

R1857 QRL029J-270 OM R 27Ø 2W J

R1858 QRL029J-180 OM R 18Ø 2W J

R1901 QRF074K-R47 UNF R 0.47Ø 7W K

R1909 QRG01GJ-470 OM R 47Ø 1W J

R1911 QRE121J-223Y C R 22kØ 1/2W J

R1912-13 QRT029J-R22 MF R 0.22Ø 2W J

R1914 QRK126J-681X C R 680Ø 1/2W J

R1915 QRE121J-6R8Y C R 6.8Ø 1/2W J

R1917 QRK126J-332X C R 3.3kØ 1/2W J

R1918 QRE121J-222Y C R 2.2kØ 1/2W J

R1919 QRE121J-684Y C R 680kØ 1/2W J

R1924 QRE121J-222Y C R 2.2kØ 1/2W J

R1930 QRE121J-223Y C R 22kØ 1/2W J

R1939 QRT039J-2R2 MF R 2.2Ø 3W J

R1940 QRE121J-181Y C R 180Ø 1/2W J

R1941 QRL029J-183 OM R 18kØ 2W J

R1951 NRSA63J-473X MG R 47kØ 1/16W J

R1952 NRSA63J-102X MG R 1kØ 1/16W J

R1953 QRE121J-820Y C R 82Ø 1/2W J

R1973 QRE121J-272Y C R 2.7kØ 1/2W J

R1975 QRE121J-223Y C R 22kØ 1/2W J

R1977 QRE121J-473Y C R 47kØ 1/2W J

R1978 NRSA63J-333X MG R 33kØ 1/16W J

R1979 QRT029J-1R2 MF R 1.2Ø 2W J

R1980 QRT029J-1R2 MF R 1.2Ø 2W J

R1998 QRZ9041-275 C R 2.7MØ 1/2W K

R1999 QRE121J-121Y C R 120Ø 1/2W J

CAPACITOR

C1001 QETN1HM-475Z E CAP. 4.7µF 50V M

C1002 QETN1HM-106Z E CAP. 10µF 50V M

C1003 QETN1CM-108Z E CAP. 1000µF 16V M

C1011-12 NCB31HK-103X C CAP. 0.01µF 50V K

C1013 NDC31HJ-151X C CAP. 150pF 50V J

C1014 QETN1CM-107Z E CAP. 100µF 16V M

C1015-16 NCB31HK-103X C CAP. 0.01µF 50V K

C1021 QFV71HJ-824Z MF CAP. 0.82µF 50V J

C1023 QETN1CM-107Z E CAP. 100µF 16V M

C1024 NCB31HK-103X C CAP. 0.01µF 50V K

C1025 NCB31HK-102X C CAP. 1000pF 50V K

C1026 QETN1HM-474Z E CAP. 0.47µF 50V M

C1027 NCB21HK-104X C CAP. 0.1µF 50V K

C1028 QETN1HM-106Z E CAP. 10µF 50V M

C1030 NCB31HK-103X C CAP. 0.01µF 50V K

C1034 NCB31HK-103X C CAP. 0.01µF 50V K

C1036 QETN1AM-477Z E CAP. 470µF 10V M

C1037 NCB31HK-103X C CAP. 0.01µF 50V K

C1038 QETN1CM-107Z E CAP. 100µF 16V M

C1041-42 QETN1HM-106Z E CAP. 10µF 50V M

C1043-44 NDC31HJ-470X C CAP. 47pF 50V J

C1045 QETN1HM-106Z E CAP. 10µF 50V M

C1046 NCB31HK-103X C CAP. 0.01µF 50V K

C1047 NDC21HJ-330X C CAP. 33pF 50V J

C1048 NCB31HK-103X C CAP. 0.01µF 50V K

C1111 QETN0JM-228Z E CAP. 2200µF 6.3V M

C1112 NCB31HK-103X C CAP. 0.01µF 50V K

C1113 QETN1HM-474Z E CAP. 0.47µF 50V M

C1114 QETN1HM-105Z E CAP. 1µF 50V M

C1115 QFV71HJ-104Z MF CAP. 0.1µF 50V J

C1116 NCB31EK-104X C CAP. 0.1µF 25V K

C1134 NDC31HJ-470X C CAP. 47pF 50V J

C1135 NDC31HJ-330X C CAP. 33pF 50V J

C1136 QENC1CM-106Z E CAP. 10µF 16V M

C1151 NCB31HK-103X C CAP. 0.01µF 50V K

C1201 NDC31HJ-100X C CAP. 10pF 50V J

C1202 QETN1HM-224Z E CAP. 0.22µF 50V M

C1203 NCB31HK-222X C CAP. 2200pF 50V K

C1233 NDC31HJ-560X C CAP. 56pF 50V J

C1237 NCB31HK-103X C CAP. 0.01µF 50V K

CAPACITOR

C1281 QFV71HJ-474Z MF CAP. 0.47µF 50V J

C1282 QETN1CM-227Z E CAP. 220µF 16V M

C1283 NCB31HK-103X C CAP. 0.01µF 50V K

C1284 QETN1HM-225Z E CAP. 2.2µF 50V M

C1285 NCB31HK-103X C CAP. 0.01µF 50V K

C1286 QETN1HM-106Z E CAP. 10µF 50V M

C1287 QETN1CM-107Z E CAP. 100µF 16V M

C1288 NCB31HK-103X C CAP. 0.01µF 50V K

C1352 QETN1CM-336Z E CAP. 33µF 16V M

C1354 QFV71HJ-154Z MF CAP. 0.15µF 50V J

C1391 QETN1CM-107Z E CAP. 100µF 16V M

C1392 NCB31HK-103X C CAP. 0.01µF 50V K

C1393-95 NCB31EK-104X C CAP. 0.1µF 25V K

C1421 NCB21HK-102X C CAP. 1000pF 50V K

C1422 QFLC1HJ-103Z M CAP. 0.01µF 50V J

C1424 QETN1VM-107Z E CAP. 100µF 35V M

C1425 QETN1VM-477Z E CAP. 470µF 35V M

C1427 QETN1HM-105Z E CAP. 1µF 50V M

C1428 QETM1EM-228 E CAP. 2200µF 25V M

C1430 NCB21CK-474X C CAP. 0.47µF 16V K

C1431 QFLC2AK-563Z M CAP. 0.056µF 100V K

C1433 QETN1EM-476Z E CAP. 47µF 25V M

C1434 NDC21HJ-100X C CAP. 10pF 50V J

C1435 NCB21HK-183X C CAP. 0.018µF 50V K

C1501 QCB32HK-151Z C CAP. 150pF 500V K

C1502 QCB32HK-331Z C CAP. 330pF 500V K

C1503 QEHR2CM-105Z E CAP. 1µF 160V M

C1504 QEZ0203-107 E CAP. 100µF 160V M

C1507-08 QEM61HK-475Z E CAP. 4.7µF 50V K

C1510 QFZ0196-382 MPP CAP. 3800pF 1.5kVH ±3%

C1513 QFZ0198-133 MPP CAP. 0.013µF 1.5kVH ±3%

C1515 QFZ0197-404 MPP CAP. 0.4µF 250V Z

C1516 QCB32HK-561Z C CAP. 560pF 500V K

C1521 QETN2EM-106Z E CAP. 10µF 250V M

C1523 QEHR1EM-108Z E CAP. 1000µF 25V M

C1525 QETN1VM-107Z E CAP. 100µF 35V M

C1526 QFV21HJ-824Z MF CAP. 0.82µF 50V J

C1527 QFLC2AJ-103Z M CAP. 0.01µF 100V J

C1531 QCB32HK-102Z C CAP. 1000pF 500V K

C1533 QETN1HM-106Z E CAP. 10µF 50V M

C1601-03 QETN1EM-476Z E CAP. 47µF 25V M

C1609-11 QFV71HJ-104Z MF CAP. 0.1µF 50V J

C1621 NCB31HK-102X C CAP. 1000pF 50V K

C1622 NCF21CZ-105X C CAP. 1µF 16V Z

C1623 NCB31HK-102X C CAP. 1000pF 50V K

C1624 NCF21CZ-105X C CAP. 1µF 16V Z

C1625 QETN1CM-107Z E CAP. 100µF 16V M

C1626 QETN1EM-108Z E CAP. 1000µF 25V M

C1627 QETN1HM-474Z E CAP. 0.47µF 50V M

C1628-29 QETN1EM-108Z E CAP. 1000µF 25V M

C1634 QETN1HM-106Z E CAP. 10µF 50V M

C1700 NCB31HK-102X C CAP. 1000pF 50V K

C1702 NCB31EK-104X C CAP. 0.1µF 25V K

C1703 NDC31HJ-181X C CAP. 180pF 50V J

C1706 QETN1HM-105Z E CAP. 1µF 50V M

C1707 QETN1CM-107Z E CAP. 100µF 16V M

C1710 NCB21EK-683X C CAP. 0.068µF 25V K

C1721 NCB31HK-103X C CAP. 0.01µF 50V K

C1722-23 NDC31HJ-390X C CAP. 39pF 50V J

C1724 NDC31HJ-471X C CAP. 470pF 50V J

C1726 NDC21HJ-561X C CAP. 560pF 50V J

C1728 NCB31HK-103X C CAP. 0.01µF 50V K

C1800 QETN1EM-107Z E CAP. 100µF 25V M

C1801 NCB31EK-104X C CAP. 0.1µF 25V K

C1802 QETN1CM-107Z E CAP. 100µF 16V M

C1804 NCB31HK-103X C CAP. 0.01µF 50V K

C1807 QETN1HM-106Z E CAP. 10µF 50V M

C1810 QENC1HM-474Z BP E CAP. 0.47µF 50V M

C1811 QENC1HM-105Z E CAP. 1µF 50V M

C1812-13 NCB31HK-102X C CAP. 1000pF 50V K

C1816 NCB31HK-153X C CAP. 0.015µF 50V K

C1853-54 QETN1CM-107Z E CAP. 100µF 16V M
