JVC AV-27D502/R User Manual

! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local
AV-27D502
36 No. 51797C
CAPACITOR
C1856-57 QETN1CM-107Z E CAP. 100µF 16V M
! C1901 QFZ9067-104 MM CAP. 0.1µF
! C1902 QFZ9067-473 MM CAP. 0.047µF
! C1904-06 QCZ9054-102 C CAP. 1000pF AC250V Z
! C1907 QEZ0169-477 E CAP. 470µF 200V M
! C1908 QCZ9054-102 C CAP. 1000pF AC250V Z
C1912 QCZ0340-222 C CAP. 2200pF
C1913 QFLC1HJ-471Z M CAP. 470pF 50V J
C1914 QETN1HM-107Z E CAP. 100µF 50V M
C1916 NDC31HJ-331X C CAP. 330pF 50V J
C1917 NCB31HK-182X C CAP. 1800pF 50V K
C1918 NCB21HK-104X C CAP. 0.1µF 50V K
C1919 QFP32GJ-103 PP CAP. 0.01µF 400V J
C1931 QEZ0203-107 E CAP. 100µF 160V M
C1933 QETN1CM-108Z E CAP. 1000µF 16V M
C1934 NDC31HJ-221X C CAP. 220pF 50V J
C1935 QETN1EM-108Z E CAP. 1000µF 25V M
C1937 QCZ0340-102 C CAP. 1000pF
C1938 QETN1CM-477Z E CAP. 470µF 16V M
C1939 QCB32HK-152Z C CAP. 1500pF 500V K
C1941 QCB32HK-102Z C CAP. 1000pF 500V K
C1942 QEHR1HM-105Z E CAP. 1µF 50V M
C1951 QETN1EM-477Z E CAP. 470µF 25V M
C1952 QETN1CM-227Z E CAP. 220µF 16V M
C1971 QETN1CM-107Z E CAP. 100µF 16V M
C1972 QETN1EM-476Z E CAP. 47µF 25V M
C1973 QETN1HM-106Z E CAP. 10µF 50V M
! C1997 QCZ9052-102 C CAP. 1000pF AC125V K
! C1998-99 QCZ9074-103 C CAP. 0.01µF AC125V M
TRANSFORMER
T1501 CE42034-002 H.DRIVE TRANSF.
! T1502 QQH0100-001 FBT
! T1921 QQS0118-001 SW TRANSF
! T1951 QQT0355-001 POWER TRANSF
COIL
! L1001 QQL244K-560Z COIL 56µH K
L1012 QQLZ014-R39 COIL 0.39µH
L1021 QRN143J-0R0X C R 0.0Ø 1/4W J
L1022 QQL244K-220Z COIL 22µH K
L1027 QRN143J-0R0X C R 0.0Ø 1/4W J
L1041 QRN143J-0R0X C R 0.0Ø 1/4W J
L1042 QQL244K-220Z COIL 22µH K
L1101 QQL244K-470Z COIL 47µH K
L1232 QQL244K-560Z COIL 56µH K
! L1511 QQR1027-002 LINIARITY COIL
L1512 QQLZ027-821 CHOKE COIL 820µH
! L1521 QQLZ018-560 HEATER CHOKE 56µH
L1700 QQL244K-4R7Z COIL 4.7µH K
L1810 QQL244J-100Z COIL 10µH J
L1931 QQL26AK-470Z COIL 47µH K
L1933 QQL26AK-470Z COIL 47µH K
L1940 QQR0582-001Z BEADS CORE
DIODE
D1010 MTZJ9.1C-T2 ZENER DIODE
D1101-02 MTZJ5.6B-T2 ZENER DIODE
D1305-10 1SS133-T2 SI.DIODE
D1352 MTZJ9.1C-T2 ZENER DIODE
D1353 1SS133-T2 SI.DIODE
D1421 1N4003-T2 SI.DIODE
D1422 MTZJ75-T2 ZENER DIODE
D1424 1SS133-T2 SI.DIODE
DIODE
D1501 RH3G-F1 SI.DIODE
! D1502 RU3AM-LFC4 SI.DIODE
D1521 RH1S-T3 SI.DIODE
D1523 RGP10J-5025-T3 SI.DIODE
D1525-26 1SS81-T5 SI.DIODE
D1527 1SR124-400A-T2 SI.DIODE
D1529 MTZJ5.1C-T2 ZENER DIODE
! D1531 MA4068N/Z1/-T2 ZENER DIODE
D1535 1SS133-T2 SI.DIODE
D1537 1SR35-400A-T2 SI.DIODE
D1601 MTZJ9.1C-T2 ZENER DIODE
D1603 MTZJ9.1C-T2 ZENER DIODE
D1606 MTZJ9.1C-T2 ZENER DIODE
D1700 MTZJ5.6B-T2 ZENER DIODE
D1701 1SS133-T2 SI.DIODE
D1703-04 MTZJ5.6B-T2 ZENER DIODE
D1716 1SS133-T2 SI.DIODE
D1721-22 1SS133-T2 SI.DIODE
D1723-24 MTZJ5.6B-T2 ZENER DIODE
D1801 1SS133-T2 SI.DIODE
D1810 MTZJ5.6B-T2 ZENER DIODE
D1811 1SS133-T2 SI.DIODE
! D1901 GSIB460-S1 BRIDGE DIODE
D1910 MA700A-T2 SI.DIODE
! D1911-13 RGP10J-5025-T3 SI.DIODE
D1914 1SS133-T2 SI.DIODE
D1915 SARS01-T2 SI.DIODE
D1917 MTZJ30A-T2 ZENER DIODE
D1918 MTZJ5.1C-T2 ZENER DIODE
D1920 1SS133-T2 SI.DIODE
D1931 RU30A-F1 SI.DIODE
D1933 RU3YX-LFC4 SI.DIODE
D1935 RU3YX-LFC4 SI.DIODE
D1941 MTZJ33A-T2 ZENER DIODE
D1945 MTZJ9.1B-T2 ZENER DIODE
D1952-53 1SS133-T2 SI.DIODE
D1954-57 1SR35-400A-T2 SI.DIODE
D1972 MTZJ15C-T2 ZENER DIODE
D1973 1SS133-T2 SI.DIODE
TRANSISTOR
Q1011 2SC5083/L-P/-T SI.TRANSISTOR
Q1021 2SC2412K/QR/-X SI.TRANSISTOR
Q1024 2SC2412K/QR/-X SI.TRANSISTOR
Q1025 2SA1037AK/QR/-X SI.TRANSISTOR
Q1041 2SA1037AK/QR/-X SI.TRANSISTOR
Q1131-33 2SC2412K/QR/-X SI.TRANSISTOR
Q1150 2SA1037AK/QR/-X SI.TRANSISTOR
Q1232-33 2SC2412K/QR/-X SI.TRANSISTOR
Q1352 2SC2412K/QR/-X SI.TRANSISTOR
Q1431 UN2212-X DEGI.TRANSISTOR
Q1501 2SC4212/Z1/ SI.TRANSISTOR
! Q1511 2SD2634-YD SI.TRANSISTOR
Q1531 2SC2785/JH/-T SI.TRANSISTOR
Q1532 2SA1037AK/QR/-X SI.TRANSISTOR
Q1621 UN2212-X DEGI.TRANSISTOR
Q1622 2SC2412K/QR/-X SI.TRANSISTOR
Q1623 UN2212-X DEGI.TRANSISTOR
Q1700 2SC2412K/QR/-X SI.TRANSISTOR
Q1701 2SA1037AK/QR/-X SI.TRANSISTOR
Q1706 2SC2412K/QR/-X SI.TRANSISTOR
Q1711 UN2212-X DEGI.TRANSISTOR
Q1810 UN2213-X DIGI TRANSISTOR
Q1951 2SD1383K/AB/-X SI.TRANSISTOR
Q1971 2SA1208/ST/Z1-T SI.TRANSISTOR
