JVC DLA-X500RBE User Manual

1-2 (No.PA048<Rev.002>)
SPECIFICATION
GENERAL
OPTICAL
ELECTRIC
INPUT CONNECTORS
OUTPUT CONNECTORS
CONTROL CONNECTORS
Design and specifications are subject to change without notice.
Type D-ILA PROJECTOR
Power requirements AC 110 to 240 V 50 Hz / 60 Hz
Power Consumption 360 W (Standby mode: 0.4 W)
Operating temperature +5°C to +35°C
Operating humidity 20%~80% (no-condensation)
Storage temperature -10°C to +60°C
Installation Height Below 5000 ft (1524 m)
Dimensions (W × H ×D) About. 455 mm × 179 mm × 472 mm
Mass 15.0 kg [X700R/XC7880R/X900R]
14.7 kg [X500R/XC5880R/XC6880R]
Remote control unit operation Distance: 7m / Angle: Horizontal =±30° Vertical =±20°
Accessories Remote control unit (RM-MH19G) × 1 [X500R/XC5880R/XC6880R]
Remote control unit (RM-MH20G) × 1 [X700R/XC7880R/X900R]
Dry cell battery (size : UM-4/AAA/R02) × 2
Power code (2m) × 1 (CHINA/US model)
Power code (2m) × 2 (Europe model)
Projection system D-ILA(reflective activematrix principle)system
D-ILA device 0.7-inch(1.7 cm) measured diagonally [H: 1920 pixels × V: 1080 pixels] × 3 <Total: 6,220,000 pixels>
Projection lens 2.0x power zoom lens (1.4 : 1 to 2.8 : 1) (Zoom / Focus: Power)
Screen size Approx. 60" to 200" (Aspect ratio : 16 : 9)
Projection distance Approx. 1.8 m to 12 m
Lamp unit UHP (Ultra High-Pressure mercury) lamp
Digital video input format 480p, 576p, 720p/50 Hz, 720p/60 Hz, 1080i/50 Hz, 1080i/60 Hz, 1080p/24Hz, 1080p/50 Hz, 1080p/
60 Hz, 3840 x 2160/24 Hz, 3840 x 2160/25 Hz, 3840 x 2160/30 Hz, 3840 x 2160/50 Hz(4:2:0), 3840
x 2160/60 Hz(4:2:0),4096 x 2160/24 Hz*
* The display image when the input signal is 4096 x 2160
3D Signal Frame Packing 720p/50 Hz, 720p/60 Hz, 1080p/24 Hz
Side-by-side 1080i/60 Hz, 1080p/60 Hz, 1080i/50 Hz, 1080p/50 Hz, 1080p/24 Hz, 720p/50 Hz, 720p/60 Hz
Top-and-bottom 720p/50 Hz, 720p/60 Hz, 1080p/24 Hz
PC input format [HDMI] VGA60, VGA59.94, SVGA60, XGA60, WXGA60, WXGA+60, SXGA60, WSXGA+60, WUXGA60
Resolution 3840 dots x 2160 dots
HDMI Input 2 system, HDMI 19 pin x 2 (HDCP compliant) Compatible with the HDMIv1.4a standard
Trigger terminal 1 system, Ø 3.5 mm DC Power Jack, DC OUT 12V/0.1A
3D synchro 3D synchro emitter dedicated terminal (1 system, mini DIN 3 pin)
RS-232C 1 system, D-sub 9-pin (Male) x 1 (External control)
LAN terminal 1 system, RJ-45 Plug x 1
