SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
2.1 DIFFERENCE POINT
*1 DLA-XC6880RB: 62,000:1
2.2 SUPPORT THE REPAIR OF EACH PCB/BLOCK
Item
DLA-X500RB
DLA-XC5880RB
DLA-XC6880RB
DLA-X500RW
DLA-X700RB
DLA-XC7880RB
DLA-X900RB
Model Code XHK-1 ← XHK-3 ←
Cabinet color Black White Black ←
Remote Controller RM-MH19G ← RM-MH20G ←
Lens shutter No ← Yes ←
Lighting Iris No ← Yes ←
Optical filter No ← Yes ←
Contrast 60,000:1 *1 ← 100,000:1 140,000:1
Picture mode 8+User5 ← 13+User5+isf,THX ←
Color Profile 9+Off ← 18+Custom5+off ←
Color temperature 10+Custom3 ← Xenon3+10+Custom3+
isf,THX
←
Gamma 4+Custom3 ← 6+Custom3+isf,THX ←
Item
Part No.
Method for repair
DLA-X500R
DLA-XC5880R
DLA-XC6880R
DLA-X700R
DLA-XC7880R
DLA-X900R
PROCESSOR PWB LCA11014-01 ←←PWB exchange
MOTOR PWB PC0210613U9 PC0106805U9 ← PWB exchange
TERMINAL-1 PWB PC0234164U9 ←←PWB exchange
TERMINAL-2 PWB PC0271151U9 ←←PWB exchange
LED&IR PWB PC0106809U9 ←←PWB exchange
KEYPAD PWB PC0106810U9 ←←PWB exchange
LAMPCOVER PWB PC0106811U9 ←←PWB exchange
TEMP SENSOR PWB PC0106817U9 ←←PWB exchange
POWER PWB PC0210605U9 ←←PWB exchange
BALLAST PWB PC023411199 ←←PWB exchange
DD PWB LCA11016-01 ←←PWB exchange
DD SUB PWB NAL0107-004 ←←PWB exchange
MEMC PWB LCA11015-01 ←←PWB exchange
OPTICAL BLOCK (Include the following PWB)
DD SUB PWB/DD PWB/ MOTOR PWB
PC0271154U9 PC0271155U9 PC0271156U9 OPTICAL BLOCK
exchange
DD FAN PC021061499 ←←
EXHAUST FAN PC010665499 ←←
DEVICE COOLING FAN PC010665399 ←←
INTAKE FAN PC010665499 ←←
EXHAUST DUCT FAN PC010665499 ←←
LAMP COOLING FAN PC027114399 ←←
PCS COOLING FAN - PB006533599 ←
FILTER PC010661199 ←←
