Precautions during Mounting
Securing (mounting) the projector
0
When this unit is to be mounted to a fixed position for
use, install it horizontally.
0
Make sure to secure the main unit to prevent accidents
such as during an earthquake.
Securing with screws
Remove the four feet at the bottom, and fasten using the
screws (M5 screws, 13 to 23 mm).
* Using screws other than those designated may cause
the unit to break down.
* Leave a clearance of at least 10 mm from the bottom
surface of the unit to allow it to take in cool air.
Securing the projector (ceiling mount)
0
Be sure to ask your dealer to install the unit for you.
Installing the unit on your own may cause the unit to
fall resulting in injury.
0
Take the necessary actions to prevent the main unit
from falling off such as during an earthquake.
0
Regardless of the warranty period, JVC is not liable for
any product damage caused by mounting the unit with
non-JVC ceiling fittings or to an environment that is not
suited for ceiling mount.
0
When using the unit with it suspended from a ceiling,
pay attention to the surrounding temperature. When a
heater is in use, the temperature around the ceiling
may be higher than expected.
0
To attach the unit to the ceiling mount bracket, set the
torque between the range of 1.5N m to 2.0N m.
Tightening with torque exceeding the above range
may cause damage to the unit, which may result the
unit to fall.
0
Install the outlet at an accessible height to unplug from
the wall. Or install the circuit breaker at an accessible
height to shut down the projector. If you need
information, please consult your authorized dealer or
specialist.
16
Set up
