(No.HC047<Rev.001>)1-11
(7) Pull out the wires from the connectors CN301, CN305 and
CN302
on the AVR board.
(8) Remove the six screws S attaching the AVR board, and
then remove the AVR board.
Fig.18
CN301
CN305S
S
S
S
AVR Board
S
S
CN302
