JVC KD-AR5500 Service Manual

3-9
Electrical parts list
Main board
Block No. [0][1]

Symbol
No.
Part No. Part Name Description Local
IC10 SAF7730HV/N224A IC
IC11 PHK04P02T-X POWER MOS FET
IC171 NJM2160BV-X IC
IC191 NJM4565V-X IC
IC271 NJM2160BV-X IC
IC291 NJM4565V-X IC
IC361 NJM4580V-X IC
IC365 BD3805F-X IC
IC381 NJM4565V-X IC
IC382 NJM2160BV-X IC
IC401 MR27T1602F248TN IC
IC402 MSM6650G3-BK IC
IC701 MN101E01LDS IC
IC702 PST9121N-X IC
IC703 BR24L32F-W-X IC
IC710 SN74AHCT126PW-X IC(DIGITAL)
IC901 HA13164A IC
IC951 TB2901HQ IC
IC971 BD9781HFP-W DC CONVERTOR
IC973 BD3930FP-X IC
IC975 BA33BC0FP-X IC
IC991 BA6956AN IC
Q1 2SB624/4/-X TRANSISTOR
Q2 UN2211-X TRANSISTOR
Q30 UN2211-X TRANSISTOR
Q703 UN2213-X DIGI TRANSISTOR
Q901 UN2111-X TRANSISTOR
Q902 UN2211-X TRANSISTOR
Q903 2SB709A/QR/-X TRANSISTOR
Q907 UN2111-X TRANSISTOR
Q908 UN2211-X TRANSISTOR
Q941 UN2111-X TRANSISTOR
Q942 UN2113-X DIGI TRANSISTOR
Q951 2SD601A/QR/-X TRANSISTOR
Q952 UN2211-X TRANSISTOR
Q953 UN2213-X DIGI TRANSISTOR
Q954 UN2113-X DIGI TRANSISTOR
Q991 UN2211-X TRANSISTOR
Q1451 KTD1304-X TRANSISTOR
Q1452 KTD1304-X TRANSISTOR
Q2451 KTD1304-X TRANSISTOR
Q2452 KTD1304-X TRANSISTOR
Q3801 KTD1304-X TRANSISTOR
Q3802 UN2111-X TRANSISTOR
Q4002 2SD1781K/QR/-X TRANSISTOR
Q4003 2SD1781K/QR/-X TRANSISTOR
Q4101 2SD1383K/B/-X TRANSISTOR
Q4151 2SD1383K/B/-X TRANSISTOR
Q4201 2SD1383K/B/-X TRANSISTOR
Q4251 2SD1383K/B/-X TRANSISTOR
Q7201 UN2211-X TRANSISTOR
Q7202 UN2211-X TRANSISTOR
Q7503 UN2211-X TRANSISTOR
Q7504 2SB624/4/-X TRANSISTOR
Q9001 2SD601A/QR/-X TRANSISTOR
Q9051 UN2211-X TRANSISTOR
AR55
00J
D701 MA111-X SI DIODE
D702 MA111-X SI DIODE
D703 MA111-X SI DIODE
D704 MA111-X SI DIODE
D705 MA8062/M/-X Z DIODE
D706 MA111-X SI DIODE
D718 SML-310LT/MN/-X LED
D719 SML-310LT/MN/-X LED
D720 SML-310LT/MN/-X LED
D901 1N5401-F64 DIODE
D904 RB160M-30-X SB DIODE
D905 RB160M-30-X SB DIODE
D941 UDZS11B-X Z DIODE
D942 MA152WA-X DIODE
D943 MA152WA-X DIODE
D944 UDZS3.3B-X Z DIODE
D945 MA111-X SI DIODE
D952 UDZS11B-X Z DIODE
D961 RB160M-30-X SB DIODE
D962 RB160M-30-X SB DIODE
D963 RB160M-30-X SB DIODE
D964 RB160M-30-X SB DIODE
D965 RB160M-30-X SB DIODE
D966 RB160M-30-X SB DIODE
D967 RB160M-30-X SB DIODE
D968 RB160M-30-X SB DIODE
D971 1SR154-400-X DIODE
D972 RB051L-40-X SB DIODE
D973 1SR154-400-X DIODE
D974 RB160M-30-X SB DIODE
D991 UDZS3.9B-X Z DIODE
D1451 MA152WA-X DIODE
D2451 MA152WA-X DIODE
D3901 UDZS4.7B-X Z DIODE
D3921 UDZS4.7B-X Z DIODE
D4001 MA111-X SI DIODE
D7501 SIR-34ST3F SI DIODE
D9051 MA152WA-X DIODE
AR55
00J
C2 QERF1CM-476Z E CAPACITOR 47uF 16V M
C3 NCB31HK-391X C CAPACITOR 390pF 50V K
C4 QERF1CM-476Z E CAPACITOR 47uF 16V M
C5 NCB31HK-391X C CAPACITOR 390pF 50V K
C13 NCB31HK-391X C CAPACITOR 390pF 50V K
C30 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C31 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C32 NDC31HJ-100X C CAPACITOR 10pF 50V J
C33 NDC31HJ-100X C CAPACITOR 10pF 50V J
C34 QERF1EM-475Z E CAPACITOR 4.7uF 25V M
C35 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C36 NCS31HJ-181X C CAPACITOR 180pF 50V J
C37 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C38 NCB31HK-102X C CAPACITOR 1000pF 50V K
C39 NCB31HK-102X C CAPACITOR 1000pF 50V K
C40 NDC31HJ-101X C CAPACITOR 100pF 50V J
C41 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C42 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C43 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C44 QERF1EM-475Z E CAPACITOR 4.7uF 25V M
C45 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C46 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C47 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C48 NEA70JM-107X E CAPACITOR 100uF 6.3V M
C50 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M
C51 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C52 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C53 NBE21CM-105X TA E CAPACITOR 1uF 16V M
C54 QERF0JM-476Z E CAPACITOR 47uF 6.3V M
C55 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C56 NDC31HJ-101X C CAPACITOR 100pF 50V J
C57 NDC31HJ-101X C CAPACITOR 100pF 50V J
C58 NEA70GM-107X E CAPACITOR 100uF 4V M
C59 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C60 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C61 QERF0JM-107Z E CAPACITOR 100uF 6.3V M
C62 QERF0JM-227Z E CAPACITOR 220uF 6.3V M
C63 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C64 NCB21CK-105X C CAPACITOR 1uF 16V K
C65 NCB31HK-471X C CAPACITOR 470pF 50V K
C66 NDC31HJ-101X C CAPACITOR 100pF 50V J
C67 NDC31HJ-101X C CAPACITOR 100pF 50V J
C68 NDC31HJ-101X C CAPACITOR 100pF 50V J
C69 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C70 NDC31HJ-101X C CAPACITOR 100pF 50V J
C71 NDC31HJ-101X C CAPACITOR 100pF 50V J
C75 NCB31CK-473X C CAPACITOR 0.047uF 16V K

