23
ENGLISH
How to use the +10 and –10 buttons
Ex. 1: To select track number 32 while
playing track number 6
Ex. 2: To select track number 8 while playing
track number 36
Selecting CD playback modes
To play back tracks at random
(Disc Random Play)
You can play back all tracks on the CD at random.
1 Press MODE to enter the
functions mode while playing a
CD.
2 Press RND (random), while
“MODE” is still on the display, so
that “DISC RND” appears on the
display.
Each time you press the button,
disc random play mode turns on
and off alternately.
When disc random play is turned on, the and
RND indicators light up on the display. A track
randomly selected starts playing.
(disc) and RND indicators
To play back tracks repeatedly
(Track Repeat Play)
You can play back the current track repeatedly.
1 Press MODE to enter the
functions mode while playing a
CD.
2 Press RPT (repeat), while
“MODE” is still on the display, so
that “TRK RPT” appears on the
display.
Each time you press the button,
track repeat play mode turns on
and off alternately.
When track repeat play is turned on, the RPT
indicator lights up on the display. The current
track starts playing repeatedly.
To play back only intros (Track Intro Scan)
You can play back the first 15 seconds of each
track sequentially.
1 Press MODE to enter the
functions mode while playing a
CD.
2 Press INT (intro), while “MODE”
is still on the display, so that
“TRK INT” appears on the
display.
Each time you press the button,
track intro scan mode turns on
and off alternately.
When track intro scan is turned on, the INT
indicator lights up on the display. The first 15
seconds of each track is played sequentially.
Track 36 \ 30 \ 20 \ 10 \ 9 \ 8
(Three times) (Twice)
(Three times)
(Twice)
Track 6 \ 10 \ 20 \ 30 \ 31 \ 32
INT indicator
RPT indicator
EN21-24_G801_G701[E_EX]f.p65 1/6/04, 12:08 PM23

Table of Contents

Other manuals for JVC KD-G801

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the JVC KD-G801 and is the answer not in the manual?

JVC KD-G801 Specifications

KD-G801

Audio Amplifier Section IconAudio Amplifier Section
maximum power output (front)50 W per channel
maximum power output (rear)50 W per channel
continuous power output (RMS, front)19 W per channel into 4 Ω
continuous power output (RMS, rear)19 W per channel into 4 Ω
load impedance4 Ω (4 Ω to 8 Ω allowance)
equalizer control range (low)±12 dB (60 Hz, 80 Hz, 100 Hz, 120 Hz)
equalizer control range (mid)±12 dB
equalizer control range (high)±12 dB (8 kHz, 10 kHz, 12 kHz, 15 kHz)
frequency response40 Hz to 20 000 Hz
signal-to-noise ratio70 dB
line-out level/impedance5.0 V/20 kΩ load (full scale)
subwoofer-out level/impedance2.0 V/20 kΩ load (full scale)
output impedance1 kΩ
CD Player Section IconCD Player Section
operating voltageDC 14.4 V (11 V to 16 V allowance)
allowable operating temperature0°C to +40°C
dimensions (installation size)182 mm × 52 mm × 159 mm
dimensions (panel size)188 mm × 58 mm × 12 mm
mass1.5 kg
frequency response5 Hz to 20 000 Hz
dynamic range96 dB
signal-to-noise ratio98 dB
Tuner Section IconTuner Section
frequency range (FM)87.5 MHz to 108.0 MHz
frequency range (AM MW)522 kHz to 1 620 kHz
frequency range (AM LW)144 kHz to 279 kHz
usable sensitivity (FM)11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity (FM)16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (FM, 400 kHz)65 dB
frequency response (FM)40 Hz to 15 000 Hz
stereo separation (FM)30 dB
capture ratio (FM)1.5 dB
sensitivity (MW)20 µV
selectivity (MW)35 dB
sensitivity (LW)50 µV

KD-G701

Audio Amplifier Section IconAudio Amplifier Section
maximum power output (front)50 W per channel
maximum power output (rear)50 W per channel
continuous power output (RMS, front)19 W per channel into 4 Ω
continuous power output (RMS, rear)19 W per channel into 4 Ω
load impedance4 Ω (4 Ω to 8 Ω allowance)
equalizer control range (low)±12 dB (60 Hz, 80 Hz, 100 Hz, 120 Hz)
equalizer control range (mid)±12 dB
equalizer control range (high)±12 dB (8 kHz, 10 kHz, 12 kHz, 15 kHz)
frequency response40 Hz to 20 000 Hz
signal-to-noise ratio70 dB
line-out level/impedance2.0 V/20 kΩ load (full scale)
output impedance1 kΩ
CD Player Section IconCD Player Section
operating voltageDC 14.4 V (11 V to 16 V allowance)
allowable operating temperature0°C to +40°C
dimensions (installation size)182 mm × 52 mm × 159 mm
dimensions (panel size)188 mm × 58 mm × 12 mm
mass1.5 kg
frequency response5 Hz to 20 000 Hz
dynamic range96 dB
signal-to-noise ratio98 dB
Tuner Section IconTuner Section
frequency range (FM)87.5 MHz to 108.0 MHz
frequency range (AM MW)522 kHz to 1 620 kHz
frequency range (AM LW)144 kHz to 279 kHz
usable sensitivity (FM)11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity (FM)16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (FM, 400 kHz)65 dB
frequency response (FM)40 Hz to 15 000 Hz
stereo separation (FM)30 dB
capture ratio (FM)1.5 dB
sensitivity (MW)20 µV
selectivity (MW)35 dB
sensitivity (LW)50 µV
