29
ENGLISH
To skip to the next or previous folder
Note:
If the folder does not contain any MP3/WMA files, it
is skipped.
Press 5 (up) while playing a disc
to skip to the next folder.
Each time you press the button
consecutively, the next folder is
located (and the first file in the
folder starts playing, if recorded).
Press (down) while playing a disc to skip back
to the previous folder.
Each time you press the button consecutively,
the previous folder is located (and the first file in
the folder starts playing, if recorded).
Selecting the playback modes
To play back files at random
(Folder Random/Disc Random Play)
You can play back all files of the current folder or
all files on the disc at random.
1 Press MODE to enter the
functions mode while playing a
disc.
2 Press RND (random), while
MODE is still on the display, so
that FLDR RND or DISC
RND appears on the display.
Each time you press the button,
the random play mode changes
as follows:
Mode
Active
Plays at random
indicator
FLDR RND and RND All files of the
indicators current folder, then
light up. files of the next
folder and so on.
DISC RND and RND All files on the disc.
indicators
light up.
Ex.: When you select FLDR RND
while listening to an MP3 file
(folder) and RND indicators
Canceled
DISC RNDFLDR RND
EN26-30_G801_G701[E_EX]f.p65 1/6/04, 12:08 PM29

Table of Contents

Other manuals for JVC KD-G801

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the JVC KD-G801 and is the answer not in the manual?

JVC KD-G801 Specifications

KD-G801

Audio Amplifier Section IconAudio Amplifier Section
maximum power output (front)50 W per channel
maximum power output (rear)50 W per channel
continuous power output (RMS, front)19 W per channel into 4 Ω
continuous power output (RMS, rear)19 W per channel into 4 Ω
load impedance4 Ω (4 Ω to 8 Ω allowance)
equalizer control range (low)±12 dB (60 Hz, 80 Hz, 100 Hz, 120 Hz)
equalizer control range (mid)±12 dB
equalizer control range (high)±12 dB (8 kHz, 10 kHz, 12 kHz, 15 kHz)
frequency response40 Hz to 20 000 Hz
signal-to-noise ratio70 dB
line-out level/impedance5.0 V/20 kΩ load (full scale)
subwoofer-out level/impedance2.0 V/20 kΩ load (full scale)
output impedance1 kΩ
CD Player Section IconCD Player Section
operating voltageDC 14.4 V (11 V to 16 V allowance)
allowable operating temperature0°C to +40°C
dimensions (installation size)182 mm × 52 mm × 159 mm
dimensions (panel size)188 mm × 58 mm × 12 mm
mass1.5 kg
frequency response5 Hz to 20 000 Hz
dynamic range96 dB
signal-to-noise ratio98 dB
Tuner Section IconTuner Section
frequency range (FM)87.5 MHz to 108.0 MHz
frequency range (AM MW)522 kHz to 1 620 kHz
frequency range (AM LW)144 kHz to 279 kHz
usable sensitivity (FM)11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity (FM)16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (FM, 400 kHz)65 dB
frequency response (FM)40 Hz to 15 000 Hz
stereo separation (FM)30 dB
capture ratio (FM)1.5 dB
sensitivity (MW)20 µV
selectivity (MW)35 dB
sensitivity (LW)50 µV

KD-G701

Audio Amplifier Section IconAudio Amplifier Section
maximum power output (front)50 W per channel
maximum power output (rear)50 W per channel
continuous power output (RMS, front)19 W per channel into 4 Ω
continuous power output (RMS, rear)19 W per channel into 4 Ω
load impedance4 Ω (4 Ω to 8 Ω allowance)
equalizer control range (low)±12 dB (60 Hz, 80 Hz, 100 Hz, 120 Hz)
equalizer control range (mid)±12 dB
equalizer control range (high)±12 dB (8 kHz, 10 kHz, 12 kHz, 15 kHz)
frequency response40 Hz to 20 000 Hz
signal-to-noise ratio70 dB
line-out level/impedance2.0 V/20 kΩ load (full scale)
output impedance1 kΩ
CD Player Section IconCD Player Section
operating voltageDC 14.4 V (11 V to 16 V allowance)
allowable operating temperature0°C to +40°C
dimensions (installation size)182 mm × 52 mm × 159 mm
dimensions (panel size)188 mm × 58 mm × 12 mm
mass1.5 kg
frequency response5 Hz to 20 000 Hz
dynamic range96 dB
signal-to-noise ratio98 dB
Tuner Section IconTuner Section
frequency range (FM)87.5 MHz to 108.0 MHz
frequency range (AM MW)522 kHz to 1 620 kHz
frequency range (AM LW)144 kHz to 279 kHz
usable sensitivity (FM)11.3 dBf (1.0 µV/75 Ω)
50 dB quieting sensitivity (FM)16.3 dBf (1.8 µV/75 Ω)
alternate channel selectivity (FM, 400 kHz)65 dB
frequency response (FM)40 Hz to 15 000 Hz
stereo separation (FM)30 dB
capture ratio (FM)1.5 dB
sensitivity (MW)20 µV
selectivity (MW)35 dB
sensitivity (LW)50 µV
