Setting Up
37English
Setting Up
Monitor Screen Setup
You can adjust image quality in video screen.
1
Press the [FNC] button.
 FUNCTION screen appears.
2
Touch [ ].
 Screen Control screen appears.
3
Adjust each item as follows.
■ [Contrast] / [Brightness] / [Color] / [Tint]
Adjusts each item.
NOTE
• Adjusting items are different depending on the
current source.
System Setup
1
Press the [FNC] button.
 FUNCTION screen appears.
2
Touch [ ].
 See the following section for each
setting.
• Set up AV (P.40)
• Set up display (P.39)
• Set up the user interface (P.38)
• Set up camera (P.35)
• Set up special (P.38)
• Set up Bluetooth (P.28)
• Set up Device (P.14)
!B5H-0357-10_JVC_KWM_K_En.indb 37 2020/04/17 16:25

JVC KW-M560BT Specifications

General

Built-in display	Yes
Display diagonal	6.8 \
Display resolution	640 x 480 pixels
USB port position	Rear
Bluetooth profiles	HFP, PBAP
USB ports quantity	1
Bluetooth functions	Audiostreaming, Handsfree calling
DIN size	2 DIN
Output power	200 W
Product color	Black
Ready for iPod	-
Audio output channels	- channels
Equalizer bands quantity	13
Maximum power per channel	- W
Audio formats supported	AAC, FLAC, MP3, SBC, WAV, WMA, WMV
Video formats supported	H.264, MPEG1, MPEG2, MPEG4
AM band range	531 - 1.611 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	AM, FM, LW, MW
Preset stations quantity	20
Package weight	1900 g

Weight and Dimensions

Weight	1300 g
